ITC4000 Series
Set Value
QCW Pulse Period
QCW Pulse Width
TEC Operating Mode
TEC Current Limit
set point Low Limit
set point High Limit
Temperature set point
Current set point
Temperature Sensor
Sensor Offset
Exponential R0 value
Exponential T0 value
b
Exponential value
Steinhart-Hart parameter A
Steinhart-Hart parameter B
Steinhart-Hart parameter C
PID Proportional value
PID Derivate value
PID Integral value
PID Oscillation Period
TEC Temperature Window
TEC Protection Reset Delay
Display
Display Value 1
Display Value 2
Display Value 3
Display Value 4
Display Value 5
Display Value 6
Display Brightness
Display Contrast
Sound Signals
88
Factory Setting
20 ms
1 ms
Constant Temperature
0.1 A
-150 °C
+150 °C
+25 °C
0 A
Thermistor (low)
0 °C
W
10.000 k
25.000 °C
3977
1.129241 EXP-3
2.341077 EXP-4
0.087755 EXP-6
1.000 A/K
0.1 A/Ks
0.0 As/K
0.2 seconds
5.000 °C (factory default: OFF)
1.0 second
6 value screen
LD Source set point
LD Current Reading
LD Voltage Reading
Photodiode Current Reading
TEC Source set point
Temperature Reading
100 %
65 %
Enabled
