4. Menu Items

a. File Menu:
i. Import Data from XG: Manually import data stored in the MULTIPAK's internal memory.
ii. Import Data from File: Import data from a previously stored data file. Does not require
iii. Export Data to File: Exports the currently displayed data to a data file, which can be imported
iv. Save Report: Saves a summary report of the currently displayed data in PDF format.
v. Save Image: Saves a screenshot of the program as an image (.bmp) file.
vi. Print: Prints a screenshot of the program.
vii. Exit: Terminates connectivity with any connected MULTIPAK and exits the program.
b. Setup Menu:
i. COM Port: Selects which COM port the program should connect through. The COM port
ii. Logging Interval: Allows for the selection of the logging time interval between acquired line
iii. Actions: Allows for the selection of which new event(s) will result in the sending of an email.
© 2013 SurgeX / Electronic Systems Protection, Inc. / Technical Support: 1-800-645-9721 / surgex.com
MULTIPAK connectivity.
for future viewing. The data file may be saved as text (.txt) or comma-separated (.csv, suitable
for viewing in MS Excel). Including the Enhanced Logging Mode data is optional.
selection is saved to a configuration file and does not need to be chosen again the next time
the program is run (unless a new MULTIPAK Data Interface Cable is used).
voltage data points when using the Enhanced Logging Mode feature. The logging time interval
selections available are: 1 second, 2 seconds, 4 seconds, 10 seconds, and 30 seconds. When
the line voltage is changing rapidly, additional data points will be recorded, regardless of the
time interval selection.
This feature is only available when the MULTIPAK is connected to a PC with an Internet
connection and the MULTIPAK software running.
