8. Graph Overview
a. Graph Control
i. The graphs used to display the recorded power quality events (normal mode) and line voltage
ii. Several control buttons are available below the graphs, depending on which mode is active:
b. Graph Data
i. Power Quality Events Graph
© 2013 SurgeX / Electronic Systems Protection, Inc. / Technical Support: 1-800-645-9721 / surgex.com
(Enhanced Logging Mode) contain Zoom, Cross Hair, and Drag functions that are useful when
analyzing data:
Legend: Press the L icon to display the Graph Legend to show the values of the
timestamped data. Pressing the icon again toggles the legend off.
Zoom: Press the magnifying glass icon to enable Zoom mode. Pressing the icon again
stops Zoom mode and restores the graph to its full display scale.
Cross Hair: Turns the cross hair on and off.
Drag: Enables/Disables Drag mode. When in Drag mode, press and hold the left mouse
button somewhere on the graph, and move the mouse. The graph will be dragged in the
corresponding direction.
1.
G1/G2: Toggles between Graph 1 (recorded power quality events) and Graph 2 (line
voltage). Available after entering Enhanced Logging Mode.
2.
**/--: Toggles the data display of Graph 2 (line voltage) between linear and discrete data
points. Available when Graph 2 is visible.
3.
Stop: Stops Enhanced Logging Mode. Available after entering Enhanced Logging Mode.
1. Overview
a. The recorded power quality events graph displays the time-stamped power
quality events (up to 60) recorded and stored in the MULTIPAK's internal
memory. The events are plotted as individual data points.
b. While the events are timestamped in the MULTIPAK's internal memory by
the elapsed time since the previous recorded event, they are plotted on the
graph with an estimated date and time, based on the connected computer's
Windows system time. The duration of a power outage is not recorded, so
the date and time of events prior to and including the most recent power
outage may not be accurate. Events with an accurate estimated date and
time are plotted with a red circle; events with a possibly inaccurate date and
time are plotted with a black circle; the time the computer was connected is
plotted with a blue square.
c. All events recorded while a computer is connected to the MULTIPAK will
have an accurate date and time stamp, since the computer will supply power
to the MULTIPAK's microcontroller in the event of a power outage (as long
as the computer stays on).
