4.3 Menu Items:

a. File Menu:
i. Import Data From XG: Manually import data stored in the Surge + Diagnostic internal memory.
ii. Import Data From File: Import data from a previously stored data file. Does not require Surge +
iii. Export Data To File: Exports the currently displayed data to a data file, which can be imported for
iv. Save Report: Saves a summary report of the currently displayed data in PDF format.
v. Save Image: Saves a screenshot of the program as an image (.bmp) file.
vi. Print: Prints a screenshot of the program.
vii. Exit: Terminates connectivity with any connected Surge + Diagnostic and exits the program.
b. Setup Menu:
i. COM Port: Selects which COM port the PCS program should connect through. The COM port
ii. Logging Interval: Allows for the selection of the logging time interval between acquired line voltage
iii. Actions: Allows for the selection of which new event(s) will result in the sending of an email. This
© 2013 SurgeX / Electronic Systems Protection, Inc. / Technical Support 800.645.9721 / www.surgex.com /
Diagnostic connectivity.
future viewing. The data file may be saved as text (.txt) or comma-separated (.csv, suitable for
viewing in MS Excel). Including the Enhanced Logging Mode data is optional.
selection is saved to a configuration file, and does not need to be chosen again the next time the
program is run (unless a new Surge + Diagnostic Data Interface Cable is used).
data points when using the Enhanced Logging Mode feature. The logging time interval selections
available are: 1 second, 2 seconds, 4 seconds, 10 seconds, and 30 seconds. When the line voltage
is changing rapidly, additional data points will be recorded, regardless of the time interval selection.
feature is only available when the Surge + Diagnostic is connected to a PC with an internet
connection and the Surge + Diagnostic software running.
