You Will Also Need

A Windows, Macintosh, Linux, or other computer that
supports TCP/IP and that is equipped with a Network
Interface Card (NIC).
A telephone wall jack to plug the Bridge into. The associated
phone line must be DSL enabled.

1.3 Quick Start Instructions

Default Communication Settings
VPI VCI Protocol (Encapsulation)
0 35 Bridge LLC (RFC 1483)
If your service provider uses all three default settings listed
above (the majority do), proceed to Connect the Bridge
below.
If your service provider uses the default VPI and VCI
numbers but the PPPoE protocol rather than the Bridge
protocol, turn to the Appendix on page 16.
If your service provider uses settings different from these
default ones (you would have been told this information when
you signed up with your DSL provider), turn to the
Appendix on page 17.
Connect the Bridge
To connect the Bridge modem hardware, all connections originate
from the Bridge's back panel.
PWR ON OFF
(For reference, we have included a table that defines these back
panel ports, or jacks; see page 14.)
1 1 1 1
Your computer should be off. Plug one end of the supplied
phone cord into the unit's ADSL jack and the other end into
the ADSL wall jack.
Chapter 1: Installation Instructions
RESET ETHERNET PHONE ADSL
5
