Zoom ADSL Modem BRIDGE 5515 User Manual page 22

6 6 6 6 In the TCP/IP dialog box, under Connect via:, select
Ethernet.
Under Configure:, highlight Manually from the Configure:
list and then enter the static IP address 10.0.0.3 (or any IP
address higher than the Bridge's 10.0.0.2 IP address) and the
subnet mask 255.255.255.0.
7 7 7 7
Close the TCP/IP dialog box. You will be asked if you want
to save the changes. Click Save.
For Mac OS X
From the Dock, choose System Preferences and then
1 1 1 1
Network. The Network pane appears.
From the Location: drop-down list box, select New
2 2 2 2
Location.... In the box, type a name of your choosing, such
as "Zoom ADSL Modem," and click OK.
Under the Show: drop-down tab, choose Built-in Ethernet
3 3 3 3
or Ethernet.
22 Zoom ADSL Bridge Modem User's Manual
