Zoom 5590 Specifications

ADSL2/2+ compliant
modem for faster ADSL
speeds
Zoom 125 Speed
Booster provides a
wireless speed boost
for data rates above
802.11g*
802.11g Wireless
Access Point with
non-blocking 802.11b
support
Built-in router provides
shared Internet access
for up to 253 concur-
rent users
Built-in 10/100 four-
port Ethernet switch
Wi-Fi Protected Access
(WPA) for improved
wireless security
Works with all popular
ADSL services
Provides Virtual
Private Networking
Passthrough
Advanced security
from hacker attacks
with Stateful Packet
Inspection, Packet
filtering, Denial of
Service attack and Port
Scan detection and
prevention
Protection against IP
Spoofing and other
common attacks
SNMP Support (Simple
Network Management
Protocol)
Two high-performance
antennas for superior
wireless range
Universal Plug and
Play (UPnP)
Easy installation
Two year warranty
Zoom ADSL X6
ADSL 2/2+ Modem + Wireless Access Point + Router
+ Advanced Firewall + 4-port Switch
Model 5590
The Zoom X6 provides an extensive range of networking and Internet access features in
a surprisingly affordable product. Advanced security features protect sensitive data in
the home or office. You'll appreciate the superior range of the X6 wireless transmissions
and the easy setup and management. And with ADSL2/2+ compliance, the X6 works
with both older ADSL protocols and the new generation of higher-speed Internet
connections.
The 802.11g Wireless Access Point provides easy network installation and freedom to
roam. With Zoom 125 Speed Booster, wireless data rates can reach 125 Mbps*. The
Model 5590 also provides complete compatability with 802.11g from other manufac-
turers operating at 54 Mbps and compatibility with the older 802.11b standard
operating at 11 Mbps. Unlike other wireless access points, the X6 can support concur-
rent connections to both 802.11(b) and (g) devices without compromising the data rate
of the higher speed devices.
With competing products, an 802.11b device on an 802.11g network can bring the
performance of the entire wireless network down to the slower 802.11b speed. The
Model 5590 is equipped with Prism
problem created with a mixed network of 802.11b and 802.11g devices and maxi-
mize network performance.
Wireless security includes the newer Wi-Fi Protected Access(WPA) protocol as well as
Wired Equivalency Protection (WEP).
Zoom ADSL gateways are backed by a two year warranty and over 28 years of
experience in the design and support of communications products.
Specifications
ADSL Compliance • Compliant with ADSL standards:
- Full-rate ANSI T1.413 Issue 2, ITU G.dmt (G.992.1) standards
- Splitterless G.lite (G.992.2) specification
Compliant with ADSL 2 standards:
- G.dmt.bis (ITU G.992.3)
Compliant with ADSL 2+ standards:
- G.992.5
- ADSL2 Annex L (Reach extended ADSL)
• DMT modulation and demodulation
• Full-rate adaptive modem
- Maximum downstream rate of 8 Mbps (ADSL), or 24 Mbps (ADSL 2+)
- Maximum upstream rate of 896 Kbps (ADSL), or 1024 Kbps (ADSL 2+)
• Supports splitterless ADSL implementation
• Interoperable with all major DSLAM manufacturers
ATM Protocols • WAN mode support: PPP over ATM (RFC 2364) and PPP over Ethernet (RFC 2516)
• LAN mode support: Bridged/Routed IP over ATM (RFC 1483) and
Classical IP over ATM (RFC 1577)
• ATM Forum UNI 3.1/4.0 PVC
• Up to eight virtual circuits
• ATM segmentation and re-assembly
• ATM AAL5 (adaption layer type 5)
• OAM F4/F5
Bridge Mode • Ethernet to ADSL self learning - Transparent Bridging (IEEE 802.1D)
• Supports up to 128 MAC learning addresses
™ Nitro Mode technology to minimize collision
Wireless Speeds
up to
125
Mbps
