SUPPLY CONFIGURATIONS
Local Control
LAN Remote Control
RS-232/485 Control
'J1' Analog Control
Series / Parallel Supplies
Advanced Parallel
INDICATORS
IP and MAC Address
Multi-drop Address
Link LED
Activity LED
LAN Status LED
Blink Identify
Local/Remote LED
BUTTONS, SWITCHES
LAN Reset
IP Address
Multi-drop Address
LAN/ RS Select
SECURITY
Web Page Password
settings
Single Client Only
Block UDP Sockets
Disable VXI-11 Discovery
Disable Ping Server
COMPLIANCE
LXI
UL, IEC, TUV,
supply with LAN installed
CE, ROHS etc
Supply may be run from front panel even if LAN is monitoring
Supply may be controlled and monitored through LAN
LAN may be disabled to use the standard RS-232/485 ports
LAN may monitor supply while analog controller sets output
Rules for standard Genesys supplies apply to LAN supplies
Rules for standard Genesys supplies apply to LAN supplies
View addresses on front panel
View RS-485 address on front panel
Indicates the Ethernet cable connected at both ends
Indicates when LAN packets detected
Red/green, indicates power supply has valid IP connection
Find the supply by remotely blinking front and rear LEDs
Indicates if LAN has control of supply output
Front panel button
Change entire IP address on front panel
Change RS-485 address on front panel
Disable LAN to enable RS-232/485 or Multi-drop slave
Can set password to prevent unauthorized or accidental changes to LAN
or power supply output settings.
Set to prevent multiple programs from taking control
Single client will block attacks through UDP sockets
Stop intruders from finding the power supply
Stop intruders from finding the power supply
Certified for LXI (rev 1.1) class C instrument
Conformances that are granted to basic power supply also apply to power
