1 �- VERIFICATION UPON RECEPTION
Upon reception of the device check the following points:
a) The device meets the specifications described in your order
b) The device has not suffered any damage during transport
c) Perform an external visual inspection of the device prior to switching it on
d) Check that it has been delivered with the following:
- An installation guide
If any problem is noticed upon reception, immediately contact the transport
company and/or CIRCUTOR's after-sales service
2 �- PRODUCT DESCRIPTION
The CVM-C4 is a device that measures, calculates and displays the main electrical parameters
in single-phase and three-phase networks.
The device has RS-485 communications, relay outputs, impulse outputs and digital inputs.
Current measurement is indirectly carried out by /5A or /1A transformers.
The device features:
- 3 keys that allow you to browse between the various screens and program the device
- LED Display to display all the parameters
- 2 relay outputs, fully programmable
- 2 digital inputs
- 2 impulse outputs, programmable
- RS-485 communications.
M527060030000
Instruction Manual
Table 3: List of CVM-C4 models
Model
80��� 270 V ~
M52706

-
CVM-C4
Auxiliary power supply
80��� 270 V

-
18�� 36 V
-

