5.4.4 Jumper Array Summary
Tables 5-13 through 5-16 show a summary of the functions for each pin of each jumper array (W1-4;
W6-9). These tables give information on jumpering a socket group for devices not found in the
jumpering tables, and also, which signal appears on each jumper pin and what pins they can connect to
on the 32-pin sockets.
•
•
In Tables 5-13 through 5-16, "From" indicates the source of the signal,
and "To" indicates the destination of a particular line.
Table 5-13. Summary of Jumper Array (W1, W6)
FUNCTION
From write strobe (gated)
To (W2 or W7) pin 5
From write strobe (ungated)
Table 5-14. Summary of Jumper Array (W2, W7)
FUNCTION
From address bit A18 (PS2)
To socket pin 1 and W3/W8 pin 2
Flash EPROM programming +12V
To socket pin 31
From write protect option
To socket pin 29
From address bit SA15
To socket pin 3
From address bit SA14
NOTE
PIN
1
2
3
PIN
XVME-956 Manual
August 1994
1
2
3
4
5
6
7
8
9
5-13
