- Page 1 C100 Counting Scale Technical Manual V2.40...
-
Page 3: Table Of Contents
CONTENTS 1. SPECIFICATIONS……………………………………………………………..1 2. PRECAUTIONS………………………………………………………………..2 3. INSTALLATION……...…………..…………………….……………………..…3 Remote Scale Setup………………………..…………………………5 4. KEYS AND FUNCTIONS…………….………………………………………6 Key board………………………………...........6 Display………………………………………………………………………7 5. OPERATION………………………………………………………….…………8 Power On/Off…………………….…………………………………………8 Switch to local / Remote Scale….…..………………………………….8 Zero……………………………….…………………………………………8 Tare………………………………………………………………………….8 Accumulation………………………………….………………………….9 Manual Accumulation……………………………………………………..10 ... -
Page 4: Specifications
C100 Series Technical Manual 1. SPECIFICATIONS DIMENSIONS Specification MODEL C100/6 C100/12 C100/30 C100/60 Part Number 899-300000 899-300001 899-300002 899-300003 Maximum Capacity 6 lb 12 lb 30 lb 60 lb 3 kg 6 kg 15 kg 30 kg Readability .0001 lb .0002 lb .0005 lb .001 lb... -
Page 5: Precautions
C100 Series Technical Manual 2. PRECAUTIONS Read this manual before operating or servicing this equipment. Follow these instructions carefully. Disconnect this equipment from a power source before cleaning or performing maintenance. Keep this manual for your future reference. ... -
Page 6: Installation
C100 Series Technical Manual 3. INSTALLATION Unpacking Carefully take the C100 out of its packaging, making sure it is not damaged and that all accessories are included. If equipped, remove the shipping safety screw. Indicated by the red label on the bottom of the C100 Accessories, 1. - Page 7 C100 Series Technical Manual SETUP Local Scale: Note: Battery should be charged for 12 hours prior to first use. Place the scale on a table. Place the stainless platter into the locating holes on the top cover. Do not press with excessive force as this could damage the load cell inside.
-
Page 8: Remote Scale Setup
C100 Series Technical Manual Remote Scale: The C100 Series can be connected to a remote base through the Remote scale port on the left side of the scale case. Place the remote scale platform in the position where it is to be used. Level the scale by adjusting the four feet. -
Page 9: Keys And Functions
C100 Series Technical Manual 4. KEYS AND FUNCTION Key Board Keys Press this key to Numeric Keys. To enter either individual unit weights or preset tare Clear incorrect entries and error conditions Decimal Point. Returns the display to zero. To clear tare weights, Storing the current weight as tare value. -
Page 10: Display
C100 Series Technical Manual Display The arrow “▼” above the symbols Weight Display Low Battery Net Weight Displayed Stable Stable Displayed Zero Zeroing Displayed Lb / kg Current Weighing Mode Unit Weight Display Smpl # of sample is very low U.Wt Unit weight is below the minimum weight... -
Page 11: Operation
C100 Series Technical Manual 5. OPERATION Initial Start-up Please allow 15 minutes of warm-up time to weight value to stabilizes after switching on. 1. Power ON/OFF Power switch is located below the bottom right side of the scale. Switch on the scale by pressing on/off. -
Page 12: Accumulation
C100 Series Technical Manual Entering a tare value using by numeric keys. This method allows you to enter a value for the tare weight from the keypad. This is useful if all containers are the same or if the container is already full but the net weight is required and the weight of the container is known. -
Page 13: Saved Data
C100 Series Technical Manual Display of Saved Data To check the total value saved, press key when the display is in zero. Total weight will be displayed two seconds. Delete Saved Data To clear the memory, press the display will be shown saved data. 1 .5 00 - 3 - Press... -
Page 14: Weighing A Sample To Determine The Unit Weight
C100 Series Technical Manual The average piece weight can be increased at any time during the counting process, by entering the displayed number of items and confirming by pressing Weighing a sample to determine the Unit Weight Reset the balance to zero or tare the empty container if necessary. ... -
Page 15: Enter A Known Weight
C100 Series Technical Manual Check Weighing or Count Pre-set Check weighing is a procedure to cause an alarm to sound when the weight or piece quantity within the a limits. Limits can be set by using numeric keys. Setting the Checking Limits Press key, the active mode will be shown Press... -
Page 16: Plu (Product Look Up)
C100 Series Technical Manual PLU (Product Look Up) PLU are used to store items. It can store up to 99 PLU numbers. The data should be entered against a particular PLU before the weighing process starts, so that the desired PLU’s can be recalled during the weighing process. -
Page 17: Entering Description Manually
C100 Series Technical Manual Entering Description Manually To set the description, press the numeric button and keep it pressed until the desired letter is displayed. The characters are according to key board. - / \ A B C D E F G H I J K L M N O... -
Page 18: Parameters
C100 Series Technical Manual 6. PARAMETERS To enter into the Parameter Turn on the scale, press during that start up. Display will be show F1 off Select the Menu Block Press key, it can choose menu block one by one. Enter the Selected Menu ... -
Page 19: Parameter Settings
C100 Series Technical Manual Parameter Setting Menu Sub Menu Description Beep Beep off Beeper is turned off Beep On in Beeper is turned on, will be sounded when in check weighing limits Fi off Beep On out Beeper will be sounded above the check weighing limits Lite Backlight will be turn on... -
Page 20: Rs-232 Output
C100 Series Technical Manual 7. RS-232 OUTPUT The C100 Series of scales come standard with an RS-232 output. Specifications: RS-232 output of weighing data ASCII code 9600 Baud 8 data bits No Parity Connector: 9 pin socket From C100 Pin 2 Output Pin 3 Input Pin 5 Signal Ground To LP50... -
Page 21: Calibration
C100 Series Technical Manual 8. CALIBRATION Note: Capacity and division size for local base can NOT be changed Turn on the scale and press during the self test. Pi n Use the numeric key to enter the password Default password 0000 Pi n - - - -... -
Page 22: Linear
C100 Series Technical Manual CALIBRATION linear Turn on the scale and press during the self test. Pi n Use the numeric key to enter the password 9999 Pi n - - - - Press to confirm Display will be show tech Local Select Local or Remote scale by pressing... -
Page 23: Technical Parameter
C100 Series Technical Manual 9. TECHNICAL PARAMETERS Enter into the parameter by pressing F1 off during the self test tech Press until tech is displayed Pi n Press to confirm, display will be shown Pi n - - - - Enter the password. - Page 24 C100 Series Technical Manual Technical Parameter Sub Menu Description Internal counts Capacity ( For Remote Scale Only ) desc 0 Set remote scale decimal point 0.00 0.000 001000 Set remote scale capacity by using numeric keys I nc 1 Set remote scale division Di v I nc Set division...
-
Page 25: Error Codes
C100 Series Technical Manual 10. ERROR CODES Error Message Description Solution ----- Maximum load exceeded Unload or reduce weight Err 4 Zero setting error Zero setting range exceeded due to switching on.(4%max) Make sure platform empty. Err 5 Key board error Check the keys and connecter. -
Page 26: Drawing
C100 Series Technical Manual 11. DRAWING - 23 -... -
Page 27: Parts List
C100 Series Technical Manual Parts List No Parts Name Qty Part number Spec SS Pan 899-300025 230mmx300mm Plastic Pan 899-300026 230mmx300mm Battery cover 899-300067 Battery 899-300022 6V/4Ah Foam Rear Overlay Top Cover Name Plate Internal Allen Screw M6x16, 8.8 Washer (M6) 200-300HV Spring Washer(M6) HRC42-50... -
Page 28: Specifications
C100 Series Technical Manual 12. SPECIFICATION Specification for Remote Scale Excitation voltage 5 VDC Signal range 0-20 mV(allows 3 mV/V LC with 5mv zero offset) Zero range 0-5 mV Sensitivity 0.02 µV/internal ADC count or better Internal ADC counts 500,000 maximum at 10 mV input Load 87 ohm minimum, 4 X 350 ohm load cells Connection... - Page 29 NOTES...
- Page 30 C100 Series Technical Manual B-TEK Scales 1510 Metric Avenue SW Canton, OH 44706 Tel: (330) 471-8900 Fax: (330) 471-8909 www.B-TEK.com...
