- Page 1 Temposonics ® Magnetostrictive Linear Position Sensors Temposonics E-Series ® Brief Instructions...
-
Page 2: Table Of Contents
Temposonics E-Series ® Brief Instructions Table of contents 1. Introduction ..................................3 2. Safety instructions ................................4 2.1 Intended use ..................................4 2.2 Forseeable misuse .................................4 2.3 Installation, commissioning and operation ........................5 2.4 Safety instructions for use in explosion-hazardous areas ....................5 2.5 Warranty ..................................5 2.6 Return ....................................5 2.7 Maintenance &... -
Page 3: Introduction
Temposonics E-Series ® Brief Instructions 1. Introduction 1.1 Purpose and use of this manual Before starting the operation of Temposonics position ® sensors read this documentation thoroughly and follow the safety information. Keep the manual for future reference! The content of this technical documentation is intended to provide information on mounting, installation and commis- sioning by qualified automation personnel or instructed... -
Page 4: Safety Instructions
Wrong connection Signal output is disturbed of ground / shield The electronics can be damaged Use of a magnet that is not Error in position certified by MTS Sensors measurement Manuals, Software & 3D Models available at: www.mtssensors.com... -
Page 5: Installation, Commissioning And Operation
Under no circumstances devices etc. are required. In the event of trouble, shut will MTS Sensors accept liability in the event of offense down the sensor and protect it against accidental operation. against the warranty rules, no matter if these have been... -
Page 6: Identification
Temposonics E-Series ® Brief Instructions 3. Identification Nameplate (e.g. E-Series EP CANopen) NOTICE Approvals and certificates Output Baud rate You will find approvals and certificates in Connection type the sensor specific operation Resolution Stroke length (e.g. 600 mm) manuals. Multi-position measurement Sensor model Part no. -
Page 7: Temposonics ® E-Series El
Temposonics E-Series ® Brief Instructions 3.3 Temposonics E-Series EL (ultra low profile sensor) ® Sensor profile with sensor element Available outputs: • Analog Position magnet • Start / Stop (Magnet slider or block magnet) • SSI • CANopen Sensor electronics housing •... -
Page 8: Installation & Mounting
Temposonics E-Series ® Brief Instructions 4. Installation & mounting 4.1 Sensor mounting Profile sensors – E-Series EP / EL / ER / EP2 The sensor is fitted on a flat machine surface using mounting Rod sensors – E-Series EH clamps. A length-dependent number of these clamps are •... -
Page 9: Magnet Installation
Temposonics E-Series ® Brief Instructions 4.2 Magnet installation Concentric mounting of U-magnet Typical use of magnets Air gap: For: EH Ring magnet 1.75 ±1 • Rotationally symmetrical magnetic field (0.07 ±0.04) For: EH & EP U-magnet • Height tolerances can be compensated Block magnet For: EP, EL, EP2 &... -
Page 10: Mounting Dimensions Of E-Series
Temposonics E-Series ® Brief Instructions 4.3 Mounting dimensions of E-Series Consider the start and end positions of the position magnets is electrically usable, the position magnet must be mechanically during the installation. To ensure that the entire stroke length mounted as follows. E-Series EH with ring- / U-magnet E-Series EP with block magnet Start position... -
Page 11: Multi-Position Measurement Distances
Temposonics E-Series ® Brief Instructions 4.4 Multi-position measurement distances Multi-position measurement with E-Series EH, EP, EL and The stroke length influences the maximum number of magnets. EP2 sensors with Analog and CANopen output is possible Note the minimum distance between the magnets. with a simultaneous measuring up to 2 positions. -
Page 12: Electrical Connections
Temposonics E-Series ® Brief Instructions 5. Electrical connections NOTICE Connect the sensor electronics housing to machine ground. Placement of installation and cabling have decisive influence Ground sensor types EP, EL, ER and EP2 via ground lug as on the sensor‘s electromagnetic compatibility (EMC). Hence shown. -
Page 13: Analog
Temposonics E-Series ® Brief Instructions 5.1 Analog 5.2 Start / Stop Signal + power supply Signal + power supply M12 male connector M12 male connector Function Function (A-coded) (A-coded) +24 VDC (−15 / +20 %) Start (+) Output 1 Start (−) DC Ground (0 V) Stop (+) Output 2... -
Page 14: Ssi
Temposonics E-Series ® Brief Instructions 5.3 SSI 5.4 CANopen Signal + power supply Signal + power supply M12 male connector M12 male connector Function Function (A-coded) (A-coded) Clock (+) Shield Clock (−) +24 VDC (−15 / +20 %) Data (+) DC Ground (0 V) Data (−) CAN_H... - Page 15 Temposonics E-Series ® Brief Instructions Notes...
- Page 16 MTS Sensor Technologie trademarks of MTS Systems Corporation in the United Sensors Division GmbH & Co. KG States; MTS SENSORS and the MTS SENSORS logo 3001 Sheldon Drive Auf dem Schüffel 9 are trademarks of MTS Systems Corporation within the Cary, N.C.
