SPALDING Arena Slam Rim Owner's Manual page 7

hARdWARe used IN thIs
sectIoN
(not actual size)
#7 (1)
#6 (1)
#5 (1)
3.
Attach special nut (7), washer (6) and spring (5) to tee-bolt (3).
6
7
3
7
7
4
3
5
Note:
Tighten nut (7) until 1/8"
of the bolt threads on
end of T-bolt (3) are
exposed.
