SPALDING Arena Slam Rim Owner's Manual page 6

hARdWARe used IN thIs
sectIoN
(not actual size)
#2 (1)
hARdWARe used IN thIs
sectIoN
(not actual size)
#4 (1)
#3 (1)
1.
Place Goal Mount bracket (2)
onto rim bracket.
2.
Insert tee-bolt (3) into goal mount bracket (2).
Secure tee-bolt with reinforcement bracket (4).
12
Note
oRIeNtAtIoN:
4
6
2
12
4
Note:
lip of goal mount
bracket will hook
over rim bracket.
3
2
