CARE AND MAINTENANCE - continued
When the "POWER" indicator light flashes, the HEPA-Rx filter needs to be replaced.
When the "LIGHT" indicator light flashes, the Activated Carbon Filter needs to be replaced.
When the "UV" indicator light flashes, it is time to replace the Germicidal UV-C+ bulb.
POWER indicator
light flashes
UV indicator
LIGHT indicator
light flashes
light flashes
Replacing the HEPA-Rx filter
When the "POWER" indicator light flashes, the HEPA-Rx filter needs to be replaced.
1. Stop the operation and unplug the unit.
2. Take out the used HEPA-Rx filter and replace with a new one (See page 8 & 9).
3. Hold the POWER button 3 seconds to reset the indicator light.
Replacing the Activated Carbon Filter
When the "LIGHT" indicator light flashes, the Activated Carbon Filter needs to be replaced.
1. Stop the operation and unplug the unit.
2. Take out the used Activated Carbon Filter and replace with a new one (See page 8 & 9).
3. Hold the LIGHT button 3 seconds to reset the indicator light.
Replacing the Germicidal UV-C+ bulb
When the UV indicator light flashes, it is time to replace the Germicidal UV-C+ bulb.
1. Stop the operation and unplug the unit.
2. Open the bottom, disconnect the power cord from Germicidal UV-C+ bulb, remove screw
and then twist to open the UV Lamp Set to take out the used Germicidal UV-C+ bulb.
3. Replace with a new one and put new Germicidal UV-C+ bulb back in the unit, close the
UV Lamp Set, re-connect the power cord and put the bottom back on (See page 8 & 9).
4. Hold the UV button 3 seconds to reset the indicator light.
13
