Surgically Clean Air SCA4000R Operational Manual

Electronic
Hide thumbs Also See for SCA4000R:
Table of Contents

Advertisement

Quick Links

WARNING: • This unit cannot be used in an atmosphere containing Explosive dust, gas or oxygen,
or in an area where flammable dust is present.
• This product can be used only where the power supply is 120V/60Hz.
• You cannot use the unit if the power voltage is different.
ELECTRONIC AIR PURIFIER
Surgically Clean Air Inc.
3451 Lake Shore Blvd. W.
Toronto, ON M8W 1N2
Tel: 1-877-440-7770
Fax: 1-416-503-9563
www.surgicallycleanair.com
info@surgicallycleanair.com
OPERATIONAL MANUAL
Model No. SCA4000R
  1   /   2 7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCA4000R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Surgically Clean Air SCA4000R

Summary of Contents for Surgically Clean Air SCA4000R

  • Page 1 ELECTRONIC AIR PURIFIER OPERATIONAL MANUAL Model No. SCA4000R WARNING: • This unit cannot be used in an atmosphere containing Explosive dust, gas or oxygen, or in an area where flammable dust is present. • This product can be used only where the power supply is 120V/60Hz.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS FOR CUSTOMER ASSISTANCE CONSUMER LIMITED WARRANTY CHAPTER 1 IMPORTANT SAFETY PRECAUTIONS CHAPTER 2 HOW IT WORKS CHAPTER 3 PART NUMBER AND NAME Part Names Part Numbers CHAPTER 4 FEATURES AND SPECIFICATIONS Features Product Specifications CHAPTER5 OPERATION Main Unit Operation Setting New Functions Remote Control Operation CHAPTER 6...

  • Page 3: For Customer Assistance

    Postal code Telephone Phone: 1-877-440-7770 Write: For service problems, guarantee information, missing items and other assistance: Surgically Clean Air Inc. 3451 Lake Shore Blvd. W. Toronto, ON M8W 1N2 Tel: 1-877-440-7770 Fax: 1-416-503-9563 Please provide the following information when you write or call: model number, serial number, date of purchase, your complete mailing address (including Postal Code), your daytime telephone number (including area code) and description of the problem.

  • Page 4: Consumer Limited Warranty

    LIMITED WARRANTY Congratulations on your investment Surgically Clean Air Inc. (Hereinafter called SCA) gives you the following limited warranty for this product only if it was originally purchased from SCA or from an Authorized SCA Dealer. SCA warrants that this product is free, under normal use and maintenance, from any defects in material and workmanship.
  • Page 5 CHAPTER 1 MPORTANT SAFETY PRECAUTIONS TO REDUCE THE RISK OF ELECTRICAL SHOCK, FIRE OR INJURY TO PERSON(S) READ THE FOLLOWING: Power Cord • Use only as described in this manual. • Use only a 120-volt outlet with grounding wire receptacle. •...

  • Page 6: Important Safety Precautions

    CHAPTER 1 IMPORTANT SAFETY PRECAUTIONS This manual classifies precautions into WARNINGS and CAUTIONS. Be sure to follow all precautions below: They are important for ensuring your safety. 1. This unit cannot be used in an atmosphere containing explosive dust, gas or in an area where flammable substances are present.
  • Page 7 CHAPTER 1 IMPORTANT SAFET PRECAUTIONS 4. The activated carbon filter must be located behind the cell. Do not try to place the activated carbon filter in front of the cell. It may cause fire! 5. After cleaning the filters, make sure to dry them thoroughly before reinstalling.
  • Page 8 CHAPTER 1 IMPORTANT SAFETY PRECAUTIONS 7. Use a fuse with proper capacity. Never use a wire in place of a fuse. Doing this may lead to malfunction or fire. 8. Do not use the unit in humid places that might be wet. Contact with water can lead to electric shock or damage the equipment.
  • Page 9 CHAPTER 1 IMPORTANT SAFETY PRECAUTIONS 1. Do not place the product in direct contact with sunlight. It may cause malfunction and deformation of the product. 2. Do not use the unit in high humidity conditions. Use the product in the ambient temperature of 0-400C.

  • Page 10: How It Works

    CHAPTER 2 HOW IT WORKS The air purifier functions as an air cleaner by helping to disinfect airborne microorganisms and removing particulates from the air. The centrifugal fans of the unit draw air through the front panel (Intake) on the front of the unit. Then it passes through the Pre-filter, the electronic cell, the activated carbon filter and the UV-Photo catalytic sterilization chamber.

  • Page 11: Part Number And Name

    CHAPTER 3 PART NUMBER AND NAME Part Numbers Part Names 210203 Plastic front panel 210101 Unit housing 200518 Front panel magnet 200312 UV lamp 201911 Pre-filter 200302 UV lamp holder & ballast 201907 Electronic cell 202522 Photo catalyst 201910 Activated carbon filter 210211 Unit Handle 210102 Filter case 201306 Fan Motor...

  • Page 12: Features And Specifications

    No screws, hooks or tools are required. The electronic cell captures small particles on aluminum plates that are simply rinsed off in the sink. Specifications Model No. SCA4000R Power Requirement 120V, 60Hz, 1A Rated Power Fan Motor...

  • Page 13: Operation

    CHAPTER 5 OPERATION Main Unit Operation Connect the Power Plug the unit into an electric outlet, the unit will be ready to run and all the indicators on the display panel will light up for 2 seconds. 1. POWER Button Press the POWER button to start the unit, re-press it to stop.
  • Page 14 • UV LAMP indicator light If the REPLACE UV LAMPS flashes, it tells the time for the UV lamps to be replaced. • CHECK indicator light When the indicator light flashes red with beeping, please contact customer service. POWER Button: •...

  • Page 15: Setting New Functions

    CHAPTER 5 OPERATION Setting new functions The unit buttons offers access to a number of functions: 1. Timer Cycle Function Setp1. Power off the unit. Step2. Hold the TIMER button for 3 seconds until the "8 hour" indicator light comes on. Step3.

  • Page 16: Remote Control Operation

    CHAPTER 5 OPERATION Remote Control Operation The battery is already set in the remote control; pull out the clear sheet from the battery cover before using. 1. POWER Button The unit will start operating when the POWER button is pressed. Pressing the button again will stop operation.
  • Page 17 After the replacement of activated carbon filter or the UV lamp, make sure to press RESET button 3 times to reset the timer. After cleaning the electronic cell, press the RESET button 3 times to reset the cell cleaning time. Note: Before pressing the RESET button, be sure the unit is plugged in.

  • Page 18: Care And Maintenance

    CHAPTER 6 CARE AND MAINTENANCE To maintain optimum performance of this air purifier, please clean the unit including the Pre-filter and electronic cell periodically. When cleaning the unit, be sure to unplug the power cord, and never handle the plug with wet hands. If so, electrical shock and bodily injury may occur as a result. Main Unit To prevent dirt or stains on the main unit, clean as often as necessary.

  • Page 19: Cleaning The Electronic Cell

    CHAPTER 6 CARE AND MAINTENANCE Cleaning the Electronic Cell Remove the electronic cell • Stop the operation and unplug the unit. • Please wait 5-10 seconds before taking off the front panel. • Pull the cell straight up and out of the filter cabinet. 6-3 Open the front panel 6-4 Removing the cell •...
  • Page 20 • Be sure there is no detergent residue around the cell ceramic insulators, especially around the square shape ceramic insulators. • Slide in the cell so the airflow arrow points toward the machine. Reset the CLEAN CELL indicator light • Hold the POWER button down on the control panel 3 seconds to reset the CLEAN CELL indicator light.  ...

  • Page 21: Replacing The Activated Carbon Filter

    CHAPTER 6 CARE AND MAINTENANCE Replacing the Activated Carbon Filter When the REPLACE CARBON FILTER indicator light flashes, the activated carbon filter needs to be replaced. • Stop the operation and unplug the unit. • Please wait 5-10 seconds before opening the front panel. •...
  • Page 22 6-6 Replace the UV Lamps After removing the UV light blocker, rotate the lamp to unlock it from the socket. Note: Remove plastic packaging from the activated carbon filter before operation. WARNING: • DO NOT reuse or clean the activated carbon filter with liquid, especially alcohol, gasoline, paint thinner, etc.

  • Page 23: Frequently Asked Questions (Faqs)

    CHAPTER 7 FREQUENTLY ASKED QUESTIONS (FQAs) Why does my air purifier spark? It is common for the purifier to spark, crackle or pop during operation. A spark indicates that the air purifier captured a large air particle. If the unit sparks continuously: •...

  • Page 24: Troubleshooting

    CHAPTER 8 TROUBLESHOOTING Service problems that appear to be major can often be solved easily. You can be your own troubleshooter by reviewing the following guide. All other servicing should be done by a SCA authorized service center. Power failure? Check other electrical appliances.

  • Page 25: Electrical Wiring Diagram

    CHAPTER 9 ELECTRICAL WIRING DIAGRAM   25   /   2 7  ...

  • Page 26: Service Reminder Schedule

    SERVICE REMINDER SCHEDULE Pre-filter Wash Reminder Electronic Cell Wash Reminder   26   /   2 7  ...
  • Page 27 Surgically Clean Air Inc.3451 Lake Shore Blvd. W. Toronto, ON M8W 1N2 Tel: 1-877-440-7770 Fax: 1-416-503-9563 www.surgicallycleanair.com info@surgicallycleanair.com SCA reserves the right to revise or modify products and/or specifications without notice. The contents of this manual are subject to change without notice.
