Surgically Clean Air Cascade White How To Do

When 'UV LAMP' indicator light flashes, it
is time for the UV-C bulbs to be replaced
1
Turn 'POWER' button off
2
Remove the Front Panel, Pre-Filter,
Electronic Cell & Carbon Plus Filter
A
Remove the front panel
B
Remove the pre-filter by pulling and turning
the two (2) clips and taking it out
C
Remove the electronic cell by using the
two (2) handles to pull the electronic cell
straight out of the air purifier
D
Pull out the carbon plus filter by using
the green tab on the bottom of the
carbon plus filter
3

Remove the Old UV-C Bulbs

A
Remove the 2 (two) silver bulb covers
B
Remove the 2 (two) UV-C bulbs by
rotating them slightly and pulling them
from the light sockets
C
Discard the old UV-C bulbs in regular
waste disposal

How to Change the UV-C Bulbs

Cascade White SCA6000C
(
A A
)
POWER
