Surgically Clean Air Cascade White Quick Setup Manual

1
Unpack the Air Purifier
A
Remove the Cascade White Air Purifier
from the shipping carton
2
Remove the Front Panel & Pre-Filter
A
Remove the front panel
B
Remove the pre-filter by pulling and turning
the two (2) clips and taking it out
3

Remove the Electronic Cell

A
Remove the upper and lower packing plates
by removing the wing nuts and pulling the
plates out of the air purifier - discard plates
B
Remove the electronic cell by using the two
(2) handles to pull the electronic cell straight
out of the air purifier
4

Remove the Carbon Plus Filter

A
Pull out the carbon plus filter from behind
the electronic cell by using the green tab
on bottom of the carbon plus filter
B
Remove the carbon plus filter from the
protective plastic bag
C
Reinsert the carbon plus filter back into place
with the green tab at the bottom facing out
Quick Set-Up Guide
Cascade White SCA6000C
( )
