Table 3 lists the type of event notifications displayed by the AutoMonitor.
Event
Invalid Card
Card Conflict
Time-overlap
Driving without
appropriate card
Card inserted
while driving
Unsaved last
session
Over-speeding
Motion sensor
data error
Rollover Event
Company lock
Rollover sensor
fault
A purpose code is recorded with the properties of an event. The description of each purpose code
is listed in Table 4.
Purpose Code
0x00
0x01
0x02
0x03
0x04
0x05
0x06
0x07
0x80
Description
Indicates that an invalid, unformatted or
unreadable, or an expired card is inserted
This event is raised when cards in the two slots
of the tachograph conflict with the operating
modes of the tachograph. Table 5 lists the
scenarios when card conflict event is raised.
This event is raised when the date/time of last
withdrawal of a driver card is later than the
current date/time of the tachograph equipment.
This event is raised when vehicle is moved while
one of the conditions listed in Table 6 is met.
This event is raised when a tachograph card is
inserted while the vehicle is in motion.
This event is raised when a driver card or a
workshop card is inserted, whose last session
was not properly closed/saved.
This event is raised when the vehicle speed
reached above the maximum speed set for the
tachograph.
This event is raised when the tachograph finds
errors in the data obtained from the motion
sensor.
This event is raised when vehicle's rolling force
is approaching closer to the rollover. The event
is recorded when the rollover detector issues a
warning or a danger alert.
This event is raised when the tachograph is
locked or unlocked by a company.
This event is raised when communication with
the rollover sensor is dropped.
Table 3: Events notification and description
Description
One of the 10 most recent (or last) events/faults
The longest event for one of the last 10 days of occurrence
One of the 5 longest events over the last 365 days
The last event for one of the last 10 days of occurrence
The most serious event of one of the last 10 days of occurrence
One of the 5 most serious events over the last 365 days
The first event or fault having occurred after the last calibration
An active/on-going event or fault
Manufacturer specific
Table 4: Purpose codes for an event
Screen Message
"Non-valid card"
"Card conflict"
"Time overlap"
"Driv'g w/o approp. card"
"Card insert. while driving"
"C/session not closed"
"Over speeding"
"Sensor fault"
"Rollover Event"
"Company lock event"
"Company unlock event"
"Roll-Sensor Err"
