3.1.2 Menu Layout

Primary Menu Sub menu 1
Eject card
Driver (Slot
1)
Driver (Slot
2)
Tachograph
Vehicle Unit
Place Entry
Spec.
Condition
Company
Date/time Date / time
Info
Rollover Status
Data
Status
GPS Tracker Data
Tracker
Card Daily
Card Events
VU Daily
Print
VU Events
Technical
Overspeed
Summary
Brake Info
Suspension
Mass
Health DTC
Engine Data
Service Log
Display
Sound
Date/Time
Settings
Daylight
Units
Language
System Info
Sub menu 2 Description
Driver slot? Ejects card in slot 1.
Co-Driver slot? Ejects card in slot 2.
Info Displays cardholder information for card in slot 1
Displays activities and events stored on card in
Display
slot 1
Prints activities and events stored on card in slot
Print
1
Info Displays cardholder information for card in slot 2
Displays activities and event stored on card in slot
Display
2
Prints activities and events stored on card in slot
Print
2
Displays activities, events, calibration record
VU Display
stored on VU
Prints activities, events, calibration record stored
VU Print
on VU
Place Begin Adds work begin place record
Place End Adds work end place record
Out of scope Adds out-of-scope specific condition
Ferry/Train Adds ferry/train specific condition
Lock-in Sets company lock-in
Lock-out Sets company lock-out
Displays current date/time
Displays rollover sensor information
Displays rollover status
Displays rollovers sensor data
Displays GPS status
Displays GPS data
Displays tracker info.
Prints daily activities from a smartcard
Prints events stored on a smartcard
Prints daily activities stored on VU
Prints events stored on VU
Prints last calibration record stored on VU
Prints overspeeding records stored on VU
Displays health summary
Displays brake performance info.
Displays suspension performance info.
Displays vehicle mass
Displays diagnostic trouble codes
Displays engine parameters
Minor Service Minor service menu
Basic Service Basic service menu
Major Service Major service menu
Display related settings
Audio related settings
Date/Timezone related settings
Daylight on/off
Display unit settings
Interface language settings
Device information
