AutoMonitor User Manual Version 7.22
Inserting a smartcard
When a valid smartcard is inserted into any slot of the VU, the device will initialise card session.
The card must be inserted when the vehicle is stationary, otherwise a 'card inserted while driving'
event will be marked. Once the device has found the card to be valid and has loaded up the
current session, the device will display a splash screen, which will include the type of card inserted
and the name of the card holder.
Ejecting a smartcard
A smartcard needs to be safely ejected before it is pulled out from its slot. To eject the card, first
make sure the vehicle is not in motion then press the Menu key and select 'Tachograph' followed
by 'Eject card' and then select the slot whose card is to be ejected. The device will write any
pending activity/date to the card and will safely disconnect it. As the card is ejected, the slot
number corresponding to the card slot will be removed from the screen, the user can then safely
pull out the card.

3.1.3 Smartcard

Smartcards are security key cards that provide access to various features of the brake meter.
Smartcards also hold identity data as well as activity data. There are four types of smartcards
currently supported in AutoMonitor. The types of cards currently supported are synchronous
memory cards.
Card
Driver Card
Card
Company
Workshop
Card
Card
Control
Description
Driver card is carried by a driver or a
co-driver.
Company card is used to lock records
to a particular company and to
download data to PC.
Workshop card is used trained
technicians to install the tachograph
equipment into a vehicle and to
perform calibration.
Control card is used by control
inspectors to download data for
control inspection purpose and to
check overspeeding.
Page 11 of 70
