Mocka Maya Six Drawer Assembly Instructions Manual page 2

Maya Six Drawer
Assembly Instructions
1
A
1
C
A
C
A
C
Insert 6x bolts (A) and 6x dowels (C) into panel [1]. Tighten with
a screwdriver.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
A
C A
C
A
C
2
2
F
A
F
F
C
F
J
F
F
3
F
F
F
F
A
C
F
K
Attach 3x CL runner track (J) to panel [2] and secure with 9x small
screws (F). Attach 3x CR runner track (K) to panel [3] and secure
with 9x small screws (F). Insert 4x bolts (A) and 4x dowels (C) into
panels [2] and [3]. Tighten with a screwdriver.
