Mocka Maya Six Drawer Assembly Instructions Manual page 10

Maya Six Drawer
Jolt Wardrobe
Assembly Instructions
17
G
H
G
7
H
H
H
G
G
Attach 8x wedges (G) to the corners of the 2x panels [7] as
shown, and secure with 8x small screws (H). Tighten with a
screwdriver.
mocka.co.nz | mocka.com.au mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
G
H
G
H
G
H
7
H
H
G
G
18
Wall Strap
1
Z
W
Attach 1x safety strap (V) and 1x washer (Z) to top panel and secure
with 1x screw (W). Tighten with a screwdriver.
V
V
Z
W
