Promet EExd User's Manual
Register Configuration C
15 14 13
r r r
Bit
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Register Configuration D -
15 14 13
1 = ON or Fitted
0
= OFF or Not Fitted
Michell Instruments
– Error Conditions
12 11 10 9
r r r r
HEX Error Condition
0001 Sensor 1 under range
0002 Sensor 1 over range
0004 Sensor 1 temperature fault
0008 Sensor 1 No flow
0010 Sensor 1 pressure transmitter failure
0020 Sensor 1 LBMMSCF calculation error
0040 NOT USED
0080 Sensor 2 under range
0100 Sensor 2 over range
0200 Sensor 2 temperature fault
0400 Sensor 2 No flow
0800 Sensor 2 pressure transmitter failure
1000 Sensor 2 LBMMSCF calculation error
2000 NOT USED
4000 Internal heater fault
Status Word
12 11 10 9
r
8 7 6 5 4
r r r r
8 7 6 5 4
r r r r
