Promet EExd User's Manual
VARIABLES Page 2
Variable
OP2max
°C/°F
Pressure
TIME
DATE
OP2/4 PARAM
VARIABLES Page 3
Variable
LOG INT'VAL
RESET LOG
INST ADDR
INT TEMP SP
SET DEFAULT
3.7.4

Dual Channel Configuration VARIABLES Pages

For more information on each variable refer to Appendix B
VARIABLES Page 1
Variable
CHN1
apply
alarm
CHN2
apply
alarm
VARIABLES Page 2
Variable
OP1min
OP1max
OP2min
OP2max
OP3min
OP3max
Michell Instruments
Brief Description
Dew-point or Pressure value that gives 20 mA on mA2 output
Temperature units selection
Pressure units selection
System time
System date
Adjustable range/options: Measured Dew point, Pressure
Brief Description
Time interval between data logs
Clears the logged data
Sets the instrument address
Set-point temperature of the internal heater
Sets the system defaults
Brief Description
Moisture measurement for Channel 1
Used for calculating dew point at an applied pressure for ideal or
natural gas
Moisture value that trips the process alarm for Channel 1
Moisture measurement for Channel 2
Used for calculating dew point at an applied pressure for ideal or
natural gas
Moisture value that trips the process alarm for Channel 2
Brief Description
Moisture value that gives 4 mA on mA1 output
Moisture value that gives 20 mA on mA1 output
Dew-point or Pressure value that gives 4 mA on mA2 output
Dew-point or Pressure value that gives 20 mA on mA2 output
Moisture value that gives 4 mA on mA3 output
Moisture value that gives 20 mA on mA3 output
OPERATION
25
