RightAngle R-STYLE WORKSTATION 50643 Instructions

K&A MANUFACTURING
6703 ZINSER ST., SCHOFIELD, WI 54476
PHONE: 800.298.4351 FAX: 866.882.9475
www.raproducts.com
VERSION DATED: 9/14/11
3
6
5
5
7
LEFT & RIGHT R-STYLE™ WORKSTATION(S)
ITEM # PART #
1 VARIES R-STYLE™ LEFT LEG ASSEMBLY
2 VARIES R-STYLE™ MODESTY PANEL
3 VARIES R-STYLE™ RIGHT LEG ASSEMBLY
4 R-STYLE A 6 x 15mm MACHINE SCREW
5 51708 M5 x 18mm SQ/PH/WSHR HEAD WOOD SCREW
6 50133 10-32 x 1/2 PHILLIPS TRUSS HEAD MACHINE SCREW VARIES
7 800512 2 X 2 WORKSURFACE JOINER PLATE
8 29SL 29SL POST LEG
INSTRUCTION # 50583
TOOLS REQUIRED FOR ASSEMBLY:
CORDLESS DRILL
#2 PHILLIPS HEAD DRIVER BIT
TAPE MEASURE
LEVEL
READ ALL THE
INSTRUCTIONS
BEFORE BEGINNING
WORKSTATION SIZES AND
CONFIGURATIONS WILL VARY.
ASSEMBLY STEPS ARE THE SAME.
2
4 1
STEPS 1-3
WORKSURFACE SUPPORT
DESCRIPTION
HARDWARE PACK # 50643 & 50648
R-STYLE™ WORKSTATION ASSEMBLY INSTRUCTIONS:
STEP 1: LAY THE WORKSURFACE ON A PROTECTED SURFACE WITH THE
INSERTS AND PILOT HOLES FACING UP. ASSEMBLE THE RIGHT LEG ASSEMBLY 3 ,
THE MODESTY PANEL 2 , AND THE LEFT LEG ASSEMBLY 1 USING (3) MACHINE
SCREWS 4 IN EACH LEG ASSEMBLY. DO NOT FULLY TIGHTEN THE SCREWS. IF
YOUR WORKSTATION HAS THE OPTIONAL WIRE MANAGEMENT CHANNEL,
INSTALL IT ACCORDING TO THE INSTRUCTIONS THAT CAME WITH THE CHANNEL.
STEP 2: PLACE THE LEG AND MODESTY PANEL ASSEMBLY ON THE WORKSUR-
FACE 7 ALIGNING THE HOLES IN THE WORKSURFACE SUPPORTS WITH THE
INSERTS IN THE WORKSURFACE. ATTACH IT USING (2 OR 3) MACHINE SCREWS 6
ON EACH WORKSURFACE SUPPORT. FULLY TIGHTEN ALL THE FASTENERS
INCLUDING THE SCREWS HOLDING THE MODESTY PANEL 2 TO THE LEFT LEG
ASSEMBLY 1 AND THE RIGHT LEG ASSEMBLY
MODESTY PANEL 2 TO THE WORKSURFACE USING (3) OR (4) WOOD SCREWS
INTO THE PILOT HOLES ON THE WORKSURFACE. DO NOT OVER-TIGHTEN THE
SCREWS. USE A LOW TORQUE SETTING ON THE DRILL.
STEP 3: ATTACH (2) JOINER PLATES
THAT WILL BUTT ANOTHER WORKSTATION. CENTER THE THE JOINER PLATE ON
THE EDGE OF THE WORKSURFACE 1/2" FROM THE FRONT AND BACK EDGES.
FASTEN WITH (2) WOOD SCREWS
STEP 4:
LAY THE WORKSURFACE ON A PROTECTED SURFACE WITH THE
PILOT HOLES FACING UP. ALIGN THE HOLES IN THE PLATE AT THE TOP OF THE
9
POST LEG WITH THE PILOT HOLES AT THE BACK CORNER OF THE WORKSUR-
FACE. ATTACH THE POST LEG WITH (4) WOOD SCREWS
QTY.
VARIES
VARIES
VARIES
VARIES
VARIES
VARIES
VARIES
3
. ATTACH THE TOP EDGE OF THE
8 ON EACH EDGE OF THE WORKSTATION(S)
5
IN EACH JOINER PLATE.
5 .
9
5
STEP 4
CORNER WORKSTATION
5
PAGE 1 OF 2
