GF Signet 2580 FlowtraMag Operating Instructions Manual

Signet 2580 FlowtraMag
*3-2580.090*
3-2580.090 Rev 3 04/20
• English
• Deutsch
• Français
Español
•
•
中文
Meter
®
Description
The GF Signet 2580 FlowtraMag is a full-bore plastic PVC in line style magnetic flowmeter.
The PVC body with titanium or Hastelloy
three times lighter in weight compared to traditional metal magmeters on the market. It is
designed for high accuracy flow measurement in short pipe runs, making it an ideal solution
for industrial applications where performance and ease of use are important.
The FlowtraMag is available in pipe sizes of DN25 (1 in.), DN50 (2 in.) and DN100 (4 in.),
optimized for performance in short pipe runs often associated with final effluent lines, well
heads and water treatment skids.
Features include:
• No moving parts
• No pressure drop
• Lighter in weight compared to traditional metal magmeters
• Reduced straight run requirements, ideal for final effluent lines, well heads and skids
• Factory calibrated with certificate (±1% of reading accuracy)
• Partially filled pipe detection status indicator
• Visual LED indicators make sensor status clear and easy to read
• Reverse flow direction configurable with 0252 Configuration Tool or GF Config Tool
Bluetooth App
®
• One device with three different outputs: field selectable Frequency or Digital (S³L),
and analog 4 to 20 mA
• On-the-fly configuration with GF Config Tool Bluetooth
• Bluetooth 4.2 capable, support iOS and Android for simple user configuration
®

Table of Contents

Warranty Information ...............................................................................2
Product Registration ................................................................................2
Safety Information ...................................................................................2
Chemical Compatibility ............................................................................2
Temperature-Pressure Graph ..................................................................2
Specifications ..........................................................................................3
Sensor Dimensions .................................................................................4
Sensor Location.......................................................................................5
Sensor Mounting Angle ...........................................................................5
Sensor Pipe Installation ...........................................................................6
Wiring Configuration ................................................................................7
Default Configurations .............................................................................8
Wiring ......................................................................................................9
App Configuration - Setup .....................................................................12
App Configuration - Monitor and Real Time Log ...................................13
App Configuration - Files .......................................................................14
App Configuration - Sensor Setup .........................................................14
Change Language .................................................................................16
Calibration .............................................................................................16
Customization and Performance Settings .............................................16
Averaging and Sensitivity Settings ........................................................17
LED Status Indicators ............................................................................17
Configuration - 0252 Configuration Tool ................................................18
Troubleshooting .....................................................................................21
Ordering Information..............................................................................24
U.S. and International Patents Pending
Operating Instructions
C electrodes has no moving parts, and is two to
®
App
®
English
