Index revision : A
From February 1st, 2017 SAMES Technologies SAS becomes SAMES KREMLIN SAS
A partir du 1/02/17, SAMES Technologies SAS devient SAMES KREMLIN SAS
User manual
TRP 501 left, TRP 501 right
TRP 502 converging
1
7021
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SAMES KREMLIN TRP 501
Summary of Contents for SAMES KREMLIN TRP 501
- Page 1 From February 1st, 2017 SAMES Technologies SAS becomes SAMES KREMLIN SAS A partir du 1/02/17, SAMES Technologies SAS devient SAMES KREMLIN SAS User manual TRP 501 left, TRP 501 right TRP 502 converging FRANCE SAMES Technologies. 13 Chemin de Malacher 38243 Meylan Cedex Tel.
- Page 2 Any communication or copying of this document, in any form whatsoever, and any use or divulging of its contents is forbidden without express written permission from SAMES Technologies. The descriptions and characteristics contained in this document may be changed without prior warning and are in no way binding on SAMES Technologies.
-
Page 3: Table Of Contents
3.1. Dimensions (mm) ........14 3.1.1. TRP 501 left and right ....... . 14 3.1.2. - Page 4 9. Spare part list - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 21 9.1. TRP 501, left assembly ......21 9.1.1.
-
Page 5: Health And Safety Instructions
SAMES Meylan France CE 0080 P/N : * ISSeP05ATEX032X** II 2 G EEx > 350mJ (Serial number) * ATEX TRP 501 / 502 Configurations TRP 501 / 502 GNM 200A 1517071 910002687 910002689 910002691 These part numbers are standard equipped with plastic nozzles and caps. -
Page 6: Precautions For Use
This document contains information that all operators should be aware of and understand before using the TRP 501 or 502 . This information highlights situations that could result in serious damage and indi- cates the precautions that should be taken to avoid them. The equipment must only be used by person- nel trained by SAMES Technologies. - Page 7 WARNING : This equipment has to be used only within areas designed for spraying with respect to EN 50176, EN 50177, EN 50223, or with similar ventilation conditions. The equipment has to be used only within ven- tilated in order to reduce risks for the health of the operators, fire or explosion. The efficiency of the extraction ventilation system has to be daily checked.
- Page 8 TRP 501/502 with plastic nozzle and cap and UHT 156 EEx e ”X” safety distance depending on the Authorised spraying distance...
-
Page 9: Important Recommendations
Use the seals recommended in this manual. For solvent-based products, seals in contact with the prod- uct must be chemically inert seals resistant to swelling or chemical attack. The TRP 501 or 502 is only guaranteed to operate correctly if it is used with seals whose size and material conform to this manual. -
Page 10: Residual Pressure
Paint or solvent dispersion may also lead topoisoning or irritation. 1.5.8. Safety devices During installation of the TRP 501 ou 502 , it is important to set up safety devices enabling high voltage power, paint, solvent and air supplies to be cut immediatly if there is a problem. -
Page 11: Guarantee
By concession, the guarantee is extended to 10000 hours on the air turbine of the TRP 501 ou 502 . The guarantee does not apply to wearing parts such as atomizing bellcups, diaphragms, clips, seals, etc. -
Page 12: Description
2. Description 2.1. General Air spray guns TRP 501 or 502 are designed for pneumatic electrostatic and automatic spraying of sin- gle-component or multi-component solvent or water-based liquid paints. The TRP 501 is fitted with one TRP500 atomizing head. The TRP 502 is fitted with two TRP500 atomizing heads. -
Page 13: Function Of The Different Parts
2.2.2. Manifold block The manifold supports and connects each atomizing head (one or two heads, depending on the model: TRP 501 or 502). • The manifolds have ducts for atomizing air, control air, paint and the HV supply. The manifolds include a paint inlet, a paint dump outlet, four air inlets fitted with plastic connections and an HV connector. -
Page 14: Characteristics
3. Characteristics 3.1. Dimensions (mm) 3.1.1. TRP 501 left and right Index revision : A 7021... -
Page 15: Trp 502 Converging
3.1.2. TRP 502 converging 3.2. Working characteristics see RT Nr 7005 3.3. Operating Principle see RT Nr 7005 Index revision : A 7021... -
Page 16: Fluid Diagrams
The atomizing air provides a fine spray and projects the mist well clear of the air cap, avoiding soiling. The fan air determines the impact spray diameter (wide or narrow). 4.1. TRP 501 ou 502 Single circuit, with dump valve without regulator Dump - D: 6/8... -
Page 17: Installation
6.2. Installing a TRP 501 or 502 • Pass the fixing tube of the manifold block TRP 501 or 502 through the fixing nut and tighten with the four screws • Connect the air and paint hoses to the manifold. -
Page 18: Assembly / Disassembly
7. Assembly / Disassembly 7.1. TRP air spray gun atomizing head • Remove the four screws from each atomizing head on the manifold. • Pull the TRP along the direction of the axis in order to separate it from the manifold. •... -
Page 19: Cleaning
8. Cleaning According to the frequency of use and in all the cases at the end of each cycle • Stop the atomizer and switch off the power supply. Before any operation, refer to the health and safety rules (see § 1.4 page WARNING : Always wear safety goggles. -
Page 20: Cleaning Of The Cap
• Every eight hours, clean the outside of the air spray gun with a clean cloth dampened with solvent. • Make sure that the cap holes are not blocked. • Dry carefully with compressed air 8.1. Cleaning of the cap •... -
Page 21: Spare Part List
9. Spare part list 9.1. TRP 501, left assembly First Con- Sale Part number Description Item Emer- sum- Unit gency able 910002687 TRP 501, left assembly TRP 500 752949 (see RT Nr 7005) High voltage unit UHT 156 EEx e... -
Page 22: Left Manifold Block
9.1.1. Left Manifold block First Con- Sale Part number Description Item Emer- sum- Unit gency able 910002688 Left manifold block F6RPDK310 Fitting - nylon 740016 Resistance 740018 Spring 746549 Fitting - nylon 910002710 TRP high voltage connection J2FENV561 O-ring - FEP X9NVCB226 Screw C M6 x 20 nylon 900002037... -
Page 23: Trp 501, Right Assembly
9.2. TRP 501, right assembly First Con- Sale Part number Description Item Emer- sum- Unit gency able 910002689 TRP 501, right assembly TRP 500 752949 (see RT Nr 7005) High voltage unit UHT 156 EEx e 1518965 (see RT Nr... -
Page 24: Right Manifold Block
9.2.1. Right Manifold block First Con- Sale Part number Description Item Emer- sum- Unit gency able 910002690 Right manifold block 746549 Fitting - nylon 910002710 TRP high voltage connection J2FENV561 O-ring - FEP X9NVCB226 Screw C M6 x 20 nylon 900002037 Cover UHT 156 F6RPUK332... -
Page 25: Trp 502 Converging
9.3. TRP 502 converging First Con- Sale Part number Description Item Emer- sum- Unit gency able 910002691 TRP 502 converging assembly TRP 500 752949 (see RT Nr 7005) High voltage unit UHT 156 EEx e 1518965 (see RT Nr 6245) Converging manifold block 910002692 (see §... -
Page 26: Converging Manifold Block
9.3.1. Converging Manifold block First Con- Sale Part number Description Item Emer- sum- Unit gency able 910002692 Converging manifold block F6RPWK342 Elbow fitting F6RPUK330 Male fitting - nylon 910002710 TRP high voltage connection X9NVCB226 Screw C M6 x 20 nylon 900002037 Cover UHT 156 F6RPDK308...
