STREAM TRAJECTORY DATA

The tables and graphs in this section give the stream trajectory for the Masterstream 4000 ER Series nozzles at various flows.
Notes on trajectory graphs:
• Graphs show approximate effective stream trajectory at 30 degrees elevation in no wind conditions. Distance to last water drops
approximately 10% farther.
• To estimate trajectories at elevations other than 30 degrees, refer to document LTT-135, available at tft.com.
• Trajectories shown are for water. The addition of foam is expected to decrease the reach by 10%.
• Tail or head winds of 20 MPH (30 KPH) may increase or decrease the range approximately 30%.
• Stream trajectory of Masterstream 4000 based on "The Trajectories of Large Fire Fighting Jets" by A.P. Hatton and M.J. Osborne,
Reference: "The International Journal of Heat and Fluid Flow", Vol 1 No 1.
• Curves C, D, and E represent trajectory data for the 2000, 3000, and 4000 settings of the 100 psi selectable nozzle.
©Copyright Task Force Tips LLC 2020
0 20
100
80
MASTERSTREAM 4000, 80 psi (5.5 bar, 550 kPa)
60
40
20
0
0 40 80 120
gpm lbs
CURVE FLOW REACTION
A 600 280
1000 470
B
C 2000 950
D 3000 1400
4000 1900
E
0 20
100
MASTERSTREAM 4000, 100 psi (7 bar, 700 kPa)
80
60
40
20
0
0 40 80 120
gpm lbs
CURVE FLOW REACTION
A 600 320
1000 530
B
2000 1100
C
3000 1600
D
4000 2100
E
0 20
100
90
MASTERSTREAM 4000, 120 psi (8.3 bar, 830 kPa)
80
70
60
50
40
30
20
10
0
0 40 80 120
gpm lbs
CURVE FLOW REACTION
A 600 350
B 1000 580
C 2000 1200
D 3000 1700
4000 2300
E
METERS
40 60 80
D
A
B
C
160 200 240
HORIZONTAL DISTANCE (FEET)
Figure 6.3A
METERS
60
40 80
A
B
160 200 240
HORIZONTAL DISTANCE (FEET)
Figure 6.3B
METERS
40 60 80
A
B
160 200 240
HORIZONTAL DISTANCE (FEET)
Figure 6.3C
8
100 120
30
20
E
10
0
280 320 360 400
l/min kgf
CURVE FLOW REACTION
A 2300 130
3800 210
B
C 7600 430
D 11000 640
15000 860
E
100 120
30
C
20
D
E
10
0
280 320 360 400
l/min kgf
CURVE FLOW REACTION
A 2300 150
3800 240
B
7600 500
C
11000 730
D
15000 950
E
100 120
30
C
20
D
10
E
0
280 320 360 400
l/min kgf
CURVE FLOW REACTION
A 2300 160
B 3800 260
C 7600 550
D 11000 770
15000 1000
E
