  • Page 1 Teknik www.teknikoffice.co.uk The stories of your life. Storage Sideboard Clifton Place Collection | Model 5421115 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
  • Page 2 Table of Contents Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps 5-21 Français 22-25 Skip the power trip. This time. Español 26-28 Safety 29-30 Warranty Page 2...
  • Page 3 Now you know Part Identifi cation our ABCs. å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts. RIGHT END (1) LOWER BACK (1) DRAWER BRACE (1)
  • Page 4 Hardware Identifi cation å Screws are shown actual size. You may receive extra hardware with your unit. ANGLED HEAD LARGE HIDDEN EXTENSION SLIDE - 2 EXTENSION RAIL - 2 CAM - 20 CAM SCREW - 20 (EXTENSION SET SHOWN SEPARATED) Angled head STRAIGHT HEAD SHORT WOOD...
  • Page 5 Step 1 Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. NOTE: If you are attaching the 421116 Hutch to your unit, å build the Hutch fi rst. Push twenty LARGE HIDDEN CAMS (1) into the å...
  • Page 6 Step 2 Peel an applique from the LARGE APPLIQUE CARD (14) å and stick one on each large hole in the BOTTOM (I). Flip the BOTTOM (I) over. å Turn and tighten four FEET (S) into the threaded holes in å...
  • Page 7 Step Step 3 Insert four SHORT WOODEN DOWELS (7) into the å BOTTOM (I). Fasten the BOTTOM MOLDINGS (J) to the BOTTOM (I). å Use six BLACK 1-1/8" FLAT HEAD SCREWS (18). NOTE: Be sure the SHORT WOODEN DOWELS insert å...
  • Page 8 Step Step 4 Turn twenty ANGLED HEAD CAM SCREWS (2) into the å ENDS (A and B) and TOP (C). Angled head (20 used) Remember: Righty tighty. Lefty loosey. Page 8...
  • Page 9 Step Step 5 Separate the EXTENSION SLIDES (U) from the EXTENSION RAILS (T) as shown in the enlarged diagram below. Be å prepared, the parts are greasy. Fasten two EXTENSION RAILS (T) to the ENDS (A and B). Use six BLACK 1/2" PAN HEAD SCREWS (20). å...
  • Page 10 Step Step 6 Insert four LONG WOOD DOWELS (5) into the LOWER å BACK (H). Fasten the UPPER BACK (E) to the LOWER BACK (H) by å pushing it onto the WOOD DOWELS in the LOWER BACK. Notch Page 10...
  • Page 11 Step Step 7 Insert three WOOD DOWELS (6) into the RIGHT END (A). å Fasten the BACKS (E and H) to the RIGHT END (A). å Tighten four HIDDEN CAMS. NOTE: Be sure the WOOD DOWELS in the RIGHT END å...
  • Page 12 Step Step 8 Insert four WOOD DOWELS (6) into the RIGHT END (A) å as shown in the upper diagram. Fasten the BOTTOM (I) to the RIGHT END (A). Tighten å two HIDDEN CAMS. NOTE: Be sure the WOOD DOWELS in the RIGHT END å...
  • Page 13 Step Step 9 Insert seven WOOD DOWELS (6) into the LEFT END (B). å Fasten the LEFT END (B) to the UPPER BACK (E), å BRACE (F), LOWER BACK (H) and BOTTOM (I). Tighten seven HIDDEN CAMS. NOTE: Be sure the WOOD DOWELS in the LEFT END insert into å...
  • Page 14 Step Step 10 Insert two SHORT WOODEN DOWELS (7) into the TOP (C). å Remember: Fasten the TOP MOLDING (D) to the TOP (C). Use three å Righty tighty. BLACK 1-1/8" FLAT HEAD SCREWS (18). Lefty loosey. NOTE: Be sure the SHORT WOOD DOWELS in the TOP å...
  • Page 15 Step Step 11 Carefully stand your unit upright. å Insert six WOOD DOWELS (6) into the ENDS (A and B) å and UPPER BACK (E). Fasten the TOP (C) to the ENDS (A and B) and UPPER å BACK (E). Tighten six HIDDEN CAMS. NOTE: Be sure the WOOD DOWELS in the ENDS and å...
  • Page 16 Step Step 12 Turn six STRAIGHT HEAD CAM SCREWS (4) into the å DRAWER FRONT (P). Push six SMALL HIDDEN CAMS (3) into the large holes in å the DRAWER SIDES (K and M) and DRAWER BRACE (O). Straight head (6 used) Arrow Arrow...
  • Page 17 Step Step 13 fi n Surface with HIDDEN CAMS i s h r f a Groove Fasten the DRAWER SIDES (K and M) and DRAWER å Slide the DRAWER BOTTOM (N) into the grooves in the å BRACE (O) to the DRAWER FRONT (P). Tighten six DRAWER SIDES (K and M) and DRAWER FRONT (P).
  • Page 18 Step 14 Fasten two EXTENSION SLIDES (U) to the DRAWER å SIDES (K and M). Use six BLACK 1/2" PAN HEAD SCREWS (20). Fasten the PULL (8) to the DRAWER FRONT (P). Use two å SILVER 1/2" FLAT HEAD SCREWS (19). Open end Use these holes.
  • Page 19 Step 15 Fasten the HINGES (12) to the DOORS (Q and R). Use å eight SILVER 1/2" FLAT HEAD SCREWS (19). Side Step: Make nachos. (Optional, but Fasten the PULLS (8) to the DOORS (Q and R). Use four å recommended.) SILVER 1/2"...
  • Page 20 Step 16 Push the RUBBER SLEEVES (16) over the METAL PINS (15). Insert the å METAL PINS into the hole locations of your choice in the ENDS (A and B). Set the ADJUSTABLE SHELF (G) onto the METAL PINS. Mounting screw Fasten the HINGES on the DOOR (R) to the HINGE BRACKETS on å...
  • Page 21 Step 17 Refer to the enlarged diagram to identify the parts on the å Adjusting screw (horizontal) HINGES. Mounting screw (depth) The DOORS may need some adjustments. Follow the å text below to make needed adjustments. DOOR ADJUSTMENTS: å To adjust the DOORS from side to side (horizontal), turn the adjusting screw in or out.
  • Page 22 Step 18 Push a GROMMET WITH CAP (9) into the hole in the TOP (C). å Peel an applique from the SMALL APPLIQUE CARD (13) and stick them on the visible HIDDEN CAMS. å To insert the drawer into your unit, line up the EXTENSION SLIDES on the drawer with the EXTENSION RAILS on the å...
  • Page 23 WARNING Please use your furniture correctly and safely. Improper use can cause safety hazards, or damage to your furniture or household items. Carefully read the following chart. Look out for: What can happen: How to avoid the problem: • Overloaded shelves. •...
