Hampstead Park TV Stand/Credenza
Model 5420834
Teknik
www.teknikoffice.co.uk
Your holder for all
things awesome.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hampstead Park 5420834 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Teknik Hampstead Park 5420834

Summary of Contents for Teknik Hampstead Park 5420834

  • Page 1 Teknik www.teknikoffice.co.uk Your holder for all things awesome. Hampstead Park TV Stand/Credenza Model 5420834 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
  • Page 2 Table of Contents Assembly Tools Required Part Identification No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identification Assembly Steps 5-21 Hammer Not actual size Français 22-24 Español 25-27 Safety 28-30 Warranty WARNING Use of a TV that is too heavy or large is hazardous. A TV that is too heavy will create a risk of a tip-over that can cause severe injury or death.
  • Page 3 Now you know Part Identification our ABCs. å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge to help distinguish similar parts from each other. Use this part identification to help identify similar parts. RIGHT END (1) D723 DRAWER BOTTOM (3) RIGHT DRAWER FRONT (1)

  • Page 4: Table Of Contents

    Hardware Identification å Screws are shown actual size. You may receive extra hardware with your unit. DRAWER LEFT - 3 CABINET LEFT - 3 35GA CABINET RIGHT - 3 35GB 35GC DRAWER RIGHT - 3 35GD TWIST-LOCK FASTENER - 8 HIDDEN CAM - 15 ®...
  • Page 5 Step 1 å Assemble your unit on a carpeted floor or on the empty carton to avoid scratching your unit or the floor. Some assembly å To begin assembly, push a SAUDER TWIST-LOCK® FASTENER (10F) (and snacks) required. into the large holes in the ENDS (A2 and B2). å...
  • Page 6 Step 2 å Push fifteen HIDDEN CAMS (1F) into the UPRIGHTS (C2 and D), BOTTOM (F), and DRAWER BRACES (M67). Then, insert the metal end of a CAM DOWEL (2F) into each HIDDEN CAM. Do not tighten the HIDDEN CAMS in this step. Arrow (15 used) Arrow...

  • Page 7: Gold 5/16" Flat Head Screw

    Step 3 å Fasten a CABINET RIGHT (35GA) to the RIGHT END (A2) and a CABINET LEFT (35GB) to the LEFT END (B2). Use four GOLD 5/16" FLAT HEAD SCREWS (3S) through holes #1 and #3. Roller end GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Roller end Page 7...
  • Page 8 Step 4 å Fasten the CABINET RIGHTS (35GA) and CABINET LEFTS (35GB) to the LOWER UPRIGHTS (D). Use eight GOLD 5/16" FLAT HEAD SCREWS (3S) through holes #1 and #3. Roller end Finished edge Roller end Roller end Finished edge GOLD 5/16"...

  • Page 9: Hidden Cam

    Step 5 å Fasten the UPRIGHTS (C2) to the TOP (E2). Tighten four Caution HIDDEN CAMS. Do not stand the unit upright without the BACK fastened. The unit may collapse. Part (E2). Another sturdier, These edges easier, friendlier component. must be even. S u r f a c H I D...

  • Page 10: Black 1-7/8" Flat Head Screw

    Step 6 å Fasten the SHELF (G3) to the UPRIGHTS (C2). Use four BLACK 1-7/8" FLAT HEAD SCREWS (2S). BLACK 1-7/8" FLAT HEAD SCREW (4 used in this step) These edges must be even. Page 10...
  • Page 11 Step 7 å Fasten the LOWER UPRIGHTS (D) to the SHELF (G3). Tighten four HIDDEN CAMS. Maximum Arrow 210 degrees å Fasten the BOTTOM (F) to the LOWER UPRIGHTS (D). Use four BLACK 1-7/8" FLAT HEAD SCREWS (2S). Minimum 190 degrees BLACK 1-7/8"...

  • Page 12: Twist-Lock Fastener

    Step 8 å Fasten the ENDS (A2 and B2) to the How to use the SAUDER TWIST-LOCK FASTENER ® TOP (E2), BOTTOM (F), and SHELF (G3). 1. Insert the dowel end of the FASTENER into the Tighten eight TWIST-LOCK® FASTENERS hole of the adjoining part.
  • Page 13 Step 9 å Fasten four CORNER BRACKETS (31G) to the BRACE (I) and BASE (M). Use eight BLACK 9/16" LARGE HEAD SCREWS (1S). å Fasten four METAL BRACKETS (4G) to the BRACE (I) and BASE (M). Use four BLACK 9/16" LARGE HEAD SCREWS (1S). å...
  • Page 14 Step 10 å Fasten the BRACE (I) and BASE (M) to the BOTTOM (F). Use twelve BLACK 9/16" LARGE HEAD SCREWS (1S) Hey! It's starting to look through the BRACKETS on the BRACE and BASE and like something! into the BOTTOM. å...
  • Page 15 Step 11 å Carefully turn your unit over onto its front edges. Lay the Caution BACK (H) over your unit. Do not stand the unit upright without the å Make equal margins along all four edges of the BACK (H). BACK fastened.
  • Page 16 Step 12 å Fasten the RIGHT DRAWER FRONT (K) to three MOLDINGS (O). Use twelve BROWN 1" FLAT HEAD SCREWS (12S). å NOTE: Be sure to position the MOLDINGS exactly as shown in the enlarged diagram. å Repeat this step for the other DRAWER FRONTS (J and L). BROWN 1"...
  • Page 17 Step 13 With the palm of your hand, The tabs should insert freely tap the DRAWER BOTTOM into the slots. Gently tilt the down into the groove. DRAWER SIDES side to side until the tabs slip into the slots. U n fi n i s h s u r f a c...
  • Page 18 Step 14 å Insert a SLIDE CAM (10A) into the DRAWER SIDES (D12 and D13). å Fasten a DRAWER RIGHT (35GC) to the RIGHT DRAWER SIDE (D12) and a DRAWER LEFT (35GD) to the LEFT DRAWER SIDE (D13). Use four GOLD 5/16" FLAT HEAD SCREWS (3S) through holes #1 and #3. å...
  • Page 19 Step 15 å Fasten a PULL (154K) to the RIGHT DRAWER FRONT (K). Use two BLACK 9/16" LARGE HEAD SCREWS (1S). å Peel a BUMPER from the BUMPER CARD (29M) and stick it on the PULL (154K) as shown. å Repeat this step for the other drawers.

  • Page 20: For Use With Televisions Weighing 95 Lbs

    Step 16 å Carefully stand your unit upright. å To insert the drawer into your unit, tip the front of the drawer down and drop the rollers on the drawer behind the rollers on the unit. Lift the front of the drawer up and slide it into the unit. WARNING å...
  • Page 21 Step 17 å To make adjustments to the drawers, loosen SCREW #3 in the SLIDES a 1/4 turn, then turn the CAM clockwise or counter-clockwise. Notice how the drawer raises or lowers as you turn the CAM. The higher the screw in the oblong hole, the higher your drawer front will be.
  • Page 22 Step WARNING Please use your furniture correctly and safely. Improper use can cause safety hazards, or damage to your furniture or household items. Carefully read the following safety information. Death or serious injury may occur when children climb on audio and/or video equipment furniture. A remote control or toys placed on the furnishing may encourage a child to climb on the furnishing and as a result may tip over onto the child.
