Cable Connections

PCBA
021078D
Push-Button
to J2

Terminal Block Connections

Alternate Power Input:
1 = +12 to 24 VDC at 1000 mA (500 mA minimum)*
2 = Power Ground*
Relay Contact:
Wire (IN)
(1A at 30 VDC for continuous loads)
3 = Normally Open Common
Terminal Block
4 = Normally Open Contact
can accept
16 AWG wire
3 4
5 = Door Sense Input
6 = Door Sense Ground Reference
*Contacts 1 and 2 on the J3 terminal block are only for
powering the Intercom from a non-PoE +12VDC power
source as an alternative to Network PoE power. Use of
these contacts for any other purpose will damage the
Intercom and void the product warranty.
© 2013, CyberData Corporation, ALL RIGHTS RESERVED
PCBA
Mounting
Screws
J2
J7
Back Plate
J6
Speaker to J7
Microphone
to J6
Mounting
Screws
1
J3 Terminal Block
6
930502E

RTFM Button

SW1

Dimensions

Maximum Recommended Wall Cutout Dimensions

Quick Reference Quick Reference
When the device is operational and linked to a network, you can
use the Reset Test Function Management (RTFM) button (SW1
[see picture]) to announce the device's IP address or restore the
device to the factory
default settings.
To announce the device's current IP address:
•
Note
To restore the device to factory default settings:
•
4.53 [115.0]
2.22 [56.3]
DIMENSIONS ARE IN INCHES [MILLIMETER]
0.25 [6.4]
0.25 [6.4]
Wall Cutout
Top Cable Entry Closed
Dimensions are in Inches [Millimeter]
930502E © 2013, CyberData Corporation, ALL RIGHTS RESERVED
Press and release the RTFM button within a five second
window.
The device will use DHCP to obtain the new IP
address (DHCP-assigned address or default to
10.10.10.10 if a DHCP server is not present).
Press and hold the RTFM button for longer than five
seconds until you hear the device announce that it is
restoring the factory default settings.
4.53 [115.0]
Top Cable Entry Opening
0.25 [6.4]
0.25 [6.4]
