H1T 045/053, 060/068 Axial Piston Tandem Pumps
Introduction
© Danfoss | September 2020
Reusable part
Non-reusable part, use a new part
Non-removable item
Option - either part may exist
Superseded - parts are not interchangeable
Measurement required
Flatness specification
Parallelism specification
External hex head
Internal hex head
Torx head
O-ring boss port
The symbols above appear in the illustrations and text of this manual. They are intended to communicate
helpful information at the point where it is most useful to the reader. In most instances, the appearance
of the symbol itself denotes its meaning. The legend above defines each symbol and explains its purpose.
Apply grease / petroleum jelly
Apply locking compound
Inspect for wear or damage
Clean area or part
Be careful not to scratch or damage
Note correct orientation
Mark orientation for reinstallation
Torque specification
Press in - press fit
Pull out with tool – press fit
Cover splines with installation sleeve
Pressure measurement/gauge location or
specification
