Parts List - Linear Technology DC2218A Demo Manual

PARTS LIST

ITEM QTY REFERENCE
LT3965 Matrix LED Dimmer Circuit Components
1 2 C1, C2
2 2 C3, C6
3 0 C42-C59(OPT)
4 2 D4, D5
5 2 D12, D13
6 16 D15-D30
7 2 Q4, Q5
8 2 R1, R2
9 2 R3, R5
10 7 R4, R6, R7, R8, R18, R19, R83
11 2 R44, R47
12 2 U1, U2
LT3797 Boost-then-Dual-Buck LED Driver Circuit Components
1 4 C4, C5, C12, C17
2 1 C9
3 2 C19, C37
4 2 C20, C21
5 1 C22
6 1 C23
7 1 C24
8 7 C25-C30, C39
9 1 C31
10 2 C32, C33
11 1 C34
12 1 C35
13 1 C36
14 1 C38
15 0 C40, C41(OPT)
16 2 D1, D2
17 1 D3
18 6 D6-D11
19 1 FB1
20 2 L1, L2
21 1 L3
22 1 L4
23 1 L6
24 2 M1, M2
25 1 M3
26 2 M4, M5
DEMO MANUAL DC2218A
PART DESCRIPTION
CAP ., 0.1µF, X7R, 50V, 10%, 0402
CAP ., 1µF, X7R, 50V, 10%, 0805
CAP ., OPTION, 0402
SCHOTTKY, RECTIFIER, 60V, 1A, SOD-123F
SCHOTTKY, RECTIFIER, 40V, 1A, SOD-123F
DIODE, PMEG4010CEJ SOD-323
TRANSISTOR, SOT-23
RES., 49.9k, 1/10W, 1% 0603
RES., 9.09k, 1/10W, 1%, 0603
RES., 10k, 1/16W, 1% 0402
RES., 1k, 1/10W, 1%, 0603
I.C. LT3965EFE TSSOP28
CAP ., 0.1µF, X7R, 100V, 10%, 0603
CAP ., 22nF, X7R, 25V, 10%, 0402
CAP ., 2200pF, X7R, 25V, 10%, 0402
CAP ., 22µF, X5R, 10V 20%, 0603
CAP ., 1000pF, C0G, 25V, 5%, 0402
CAP ., ALUM., 33µF, 50V, 6.3X7.7
CAP ., 4.7µF, X7R, 50V 10%, 1210
CAP ., 10µF, X5R, 50V 10%, 1206
CAP ., 1µF, X7R, 50V, 10%, 0805
CAP ., 1µF, X7R, 16V, 10%, 0603
CAP ., 0.22µF, X5R, 10V 10%, 0603
CAP ., 0.1µF, X7R, 16V, 10%, 0603
CAP ., 10µF, X5R, 10V, 10%, 0603
CAP ., 0.1µF, X7R, 50V, 10%, 0402
CAP ., 0805
DIODE, DFLS260, POWER-DI-123
DIODE, PDS360, POWER-DI-5
DIODE, PMEG6010CEJ SOD-323
BEAD, CHIP , 742792150
INDUCTOR, 33µH,
INDUCTOR, 15µH
IND., 47µH, SD SERIES, IND-SD25
INDUCTOR, 10µH
N-CH MOSFET, Si7308DN, POWERPAK-1212-8
N-CH MOSFET, Si7850DP , POWERPAK SO8
P-CH MOSFET, Si7611DN, POWERPAK-1212-8
MANUFACTURER/PART NUMBER
MURATA, GRM155R71H104KE14D
MURATA, GRM21BR71H105KA12L
NXP ., PMEG6010CEH, 115
NXP ., PMEG4010CEH, 115
NXP ., PMEG4010CEJ, 115
DIODES INC., FMMT593TA
VISHAY, CRCW060349K9FKEA
VISHAY, CRCW06039K09FKEA
VISHAY, CRCW040210K0FKED
VISHAY, CRCW06031K00FKEA
LINEAR TECH., LT3965EFE#PBF
MURATA, GRM188R72A104KA35D
MURATA, GRM155R71E223KA61D
MURATA, GRM155R71E222KA01D
MURATA, GRM188R61A226ME15D
MURATA, GRM1555C1E102JA01D
PANASONIC, EEHZA1H330XP
MURATA, GRM32ER71H475KA88L
MURATA, GRM31CR61H106KA12L
MURATA, GRM21BR71H105KA12L
MURATA, GRM188R71C105KA12D
MURATA, GRM188R61A224KA01D
MURATA, GRM188R71C104KA01D
MURATA, GRM188R61A106KE69D
MURATA, GRM155R71H104KE14D
DIODES/ZETEX, DFLS260-7
DIODES/ZETEX, PDS360-13
NXP ., PMEG6010CEJ, 115
WURTH ELEKTRONIK, 742792150
WURTH ELEKTRONIK, 7447789133
WURTH ELEKTRONIK, 7443551151
EATON BUSSMANN, SD25-470-R
WURTH ELEKTRONIK, 7443251000
VISHAY, Si7308DN-T1-GE3
VISHAY, Si7850DP-T1-GE3
VISHAY, Si7611DN-T1-GE3 (LEAD-FREE #)
dc2218af
7
