DEMO MANUAL DC2218A
PARTS LIST
ITEM QTY REFERENCE
27 1 R10
28 2 R11, R12
29 1 R13
30 1 R15
31 2 R16, R17
32 2 R25, R26
33 2 R28, R31
34 3 R29, R30, R35
35 1 R32
36 3 R33, R38, R39
37 1 R40
38 1 R41
39 2 R42, R43
40 1 R45
41 1 U3
Additional Demo Board Circuit Components
1 1 DC2026C
2 2 C7, C8
3 3 C10, C11, C13
4 1 C14
5 1 C15
6 1 C16
7 1 C18
8 1 D14
9 1 D31
10 1 D32
11 1 L5
12 16 LED1-LED16
13 3 Q1, Q2, Q3
14 1 R9
15 1 R14
16 3 R20, R21, R48
17 1 R22
18 1 R23
19 1 R24
20 1 R27
21 3 R34, R36, R37
22 1 R46
23 4 R49, R50, R51, R52
24 2 R53, R54
8
PART DESCRIPTION
RES., 47.5k, 1/16W, 1% 0402
RES., 5.6k, 1/16W, 5% 0402
RES., 15k, 1/16W, 5% 0402
RES., 0.02Ω, 0.5W, 1% 1206
RES., 0.05Ω, 0.5W, 1% 1206
RES., 0.5Ω, 0.5W, 1% 1206
RES., 44.2k, 1/16W, 1% 0402
RES., 1M, 1/10W, 1% 0603
RES., 43.2k, 1/16W, 1% 0402
RES., 10k, 1/10W, 1% 0603
RES., 249k, 1/16W, 1% , 0402
RES., 38.3k, 1/16W, 1% , 0402
RES., 100k, 1/10W, 1%, 0603
RES., 100k, 1/16W, 1% , 0402
I.C., LT3797EUKG QFN(52)(UKG)-7MMX8MM
LINDUINO DEMO BOARD
CAP ., 0.1µF, X7R, 16V, 10%, 0603
CAP ., 1µF, X7R, 16V, 10%, 0603
CAP ., 0.22µF, X5R, 6.3V 10%, 0402
CAP ., 1µF, X7R, 50V, 10%, 0805
CAP , 22µF, X7R, 6.3V, 20%, 1206
CAP , 22pF, NPO, 5% 50V, 0402
LED, GREEN, DIFFUSED, 0805
LED, YELLOW, DIFFUSED, 0805
LED, RED
IND, 33µH
LED, XLAMP XP-E2 SERIES
TRANSISTOR, MOSFET, N-CH 60V, 150mA, SOT-23
RES., 57.6k, 1/10W, 1%, 0603
POT., 10k, 10%, 1 TURN
RES., 1k, 1/10W, 1%, 0603
RES., 10k, 1/10W, 1%, 0603
RES., 604k, 1/16W, 1% , 0402
RES., 200k, 1/16W, 1% , 0402
RES., 100Ω, 1/10W, 5% 0603
RES., 5.1k, 1/10W, 5% 0603
RES., 2.49k, 1W, 5% 2512
RES., 0Ω, 1/10W, 0603
RES., 0Ω, 1/16W, 0402
MANUFACTURER/PART NUMBER
VISHAY, CRCW040247K5FKED
VISHAY, CRCW04025K60JNED
VISHAY, CRCW040215K0JNED
SUSUMU, RL1632R-R020-F
SUSUMU, RL1632R-R050-F
SUSUMU, RL1632R-R500-F
VISHAY, CRCW040244K2FKED
VISHAY, CRCW06031M00FKEA
VISHAY, CRCW040243K2FKED
VISHAY, CRCW060310R0FKEA
VISHAY, CRCW0402249KFKED
VISHAY, CRCW040238K3FKED
VISHAY, CRCW0603100KFKEA
VISHAY, CRCW0402100KFKED
LINEAR TECH., LT3797EUKG#PBF
MURATA, GRM188R71C104KA01D
MURATA, GRM188R71C105KA12D
MURATA, GRM155R60J224KE01D
MURATA, GRM21BR71H105KA12L
MURATA, GRM31CR70J226KE19L
MURATA, GRM1555C1H220JA01D
AVAGO, HSMG-C170
AVAGO, HSMY-C170
WURTH ELEKTRONIK, 150080SS75000
TOKO, A914BYW-330M=P3
CREE INC., XPEBWT-L1-0000-00D50
DIODES INC., VN10LFTA
VISHAY, CRCW060357K6FKEA
BOURNS, 91A1A-B28-A15L
VISHAY, CRCW06031K00FKEA
VISHAY, CRCW060310K0FKEA
VISHAY, CRCW0402604KFKED
VISHAY, CRCW0402200KFKED
VISHAY, CRCW0603100RJNEA
VISHAY, CRCW06035K10JNEA
VISHAY, CRCW25122K49FKEG
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW04020000Z0ED
