Note: The Barometric Altitude shown is from the barometric sensor in the device
and not from the Mode-S transponder.
3.3.4

Obstacle Database

Shows information about the installed obstacle database and appurtenant license.
If no database is installed, or the current one is expired, see Section 5.2 for details.
3.3.5

Wi-Fi

Shows Wi-Fi connection information (SSID and password) to connect additional
devices to FLARM Hub. When delivered or after being reset to factory default, the
connection information is the same as printed on the device sticker. The QR code
and connection information shown takes changes to the SSID and Wi-Fi password
into account.
Click on the eye icon to reveal/hide the password.
3.4

Configuration

The different configuration pages can be used to configure FLARM, the Wi-Fi and
Bluetooth interfaces, and FLARM Hub. FLARM can also be configured by uploading
a configuration file.
3.4.1

FLARM

FLARM can be configured using either the configuration page in FLARM Hub or by
using a configuration file created e.g. by the
configuration file can be uploaded at the bottom of the FLARM Hub configuration
page. When the upload has finished, the number of configuration items applied,
and if there were any errors, will be indicated.
Note: When using a configuration file, the configuration should be verified in
FLARM Hub after uploading the file.
Explanations for each field are available as a tooltip by hovering over or clicking
on the question mark next to each field. Check the box "Show advanced
configuration items" to show additional customization options.
When a configuration item is changed (selecting a dropdown item, radio button,
or moving focus away from a text field), the configuration is automatically applied
to FLARM. No additional step is necessary to apply the value. A successful change
of the configuration item is indicated as a green border around, and a green
checkmark inside, the field. An incorrect value is indicated as a red border around,
and a red exclamation mark inside, the field.
