8.4

GDL 90

Fusion automatically streams the GDL 90 protocol to connected mobile devices.
This protocol is based on datagrams (UDP) and connectionless. The destination
port is 4000, unless when the auto-discovery mechanism is used (e.g. ForeFlight).
GLD 90 transports traffic and position data, but many other aspects of FLARM ICD
are missing. Usually, in the app this is called "GDL 90 Compatible device" or
similar, and it can be added via the settings in the normal way.
8.5

Apps

The settings for some common apps are listed below. For other apps, use the
generic connection settings as specified above.
Air Navigation Pro
Select "FLARM [...]" as Traffic Source. Manually configure the following settings
(no "Pin code" is needed):
IP Address: 10.10.10.10
Port number: 2000
Airmate
Select "ADS-B Device" (GDL 90).
EasyVFR
Select "GDL90 Stratux [...]".
ForeFlight
Connects via auto-discovery (GDL 90). No settings are necessary. The auto-
discovery mechanism allows to use a non-standard destination port (4000).
Helios Horizon
Select "Stratux or Compatible GDL90 Device".
Sky-Map
Use the following settings under WLAN Interface configuration:
IP: 10.10.10.10
Port: 2000
Password: (none)
