4

USB Flash Drive Operation

PowerFLARM Fusion has a built-in USB A 2.0 connector for a USB flash drive. It
can be used for device updates, configuration, and readout of device information
and flight logs (IGC). A USB extension cable with connector is normally installed
in the instrument panel for easy access.
Note: The FLARM Hub firmware can only be updated via FLARM Hub.
Note: The USB flash drive must not be connected during flight.
USB flash drive transactions take place automatically when Fusion is switched ON
with a USB flash drive connected. In addition, transactions can take place when
triggered by a FLARM display or flight computer (e.g. readout of flight logs).
Transactions when switching Fusion ON are executed in the following sequence:
Apply device configuration (FLARMCFG.TXT)

Write device information (FLARMDEV.CSV)

Updates: PowerFLARM firmware, obstacle database, licenses. Fusion restarts

if any update is done (Status LED OFF for three seconds); this is to allow
expedited updating of multiple updates.
Flight logs readout

USB flash drives properties:
Formatted as FAT16, FAT32, or exFAT (NTFS will not work)

Capacity <= 128 GB

USB 2.0 connector (not USB 3.0)

Recommendations and additional information for USB flash drive usage:
Use a dedicated USB flash drive for PowerFLARM Fusion (Exception: Updates

of multiple Fusion devices to the same firmware version).
Leave flight logs (IGC files) on the USB flash drive, space permitting. This

will reduce the time needed for readout since files already on the flash drive
are skipped.
IGC files will have the correct timestamp, corresponding to when the flight

took place. This allows to sort by date on a PC.
Do not have multiple obstacle database files on the USB flash drive.

Fusion will skip firmware, license, and obstacle database files which are

already installed.
