FLARM Technology Ltd
Hinterbergstrasse 15
CH-6330 Cham
Download the latest PowerFLARM firmware file (.fw) and FLARM Hub firmware file
(.bin) under the following link:
https://flarm.com/support/firmware-updates/
Obstacle database updates with license can be purchased under the following link:
https://flarm.com/product-category/obstacle-databases/
3.6
IGC file download
IGC files can be downloaded from the IGC Files page under the Maintenance menu
section. Click the button at the top to populate the table with all IGC files that are
available on the device. The list is sorted in reverse chronological order (newest
first). Click on a file to download it.
3.7
Traffic Monitor
The traffic monitor displays directional traffic (FLARM and ADS-B) received by
Fusion, using symbology similar to TCAS. Non-directional Mode-S targets are not
shown. It does not issue collision warnings.
The traffic monitor can be used e.g. to troubleshoot display connectivity and
configuration issues. It should not be used for collision avoidance purposes. When
on the ground, aircraft with Stealth or No Track mode enabled will not be shown.
When using the traffic monitor, note the zoom level and vertical axis reference
(North Up or Track Up).
3.8
Interactive Data Port
An interactive bi-directional data port is available with the same functionality as
the physical data ports. This can be used e.g. for troubleshooting when instructed
by 3rd party support.
3.9
Range Analyzer
The CARP (Continuous Analyzer of Radio Performance) Range Analyzer always runs
in the background during flight and continuously integrates the receive range over
time. The range is based on receive range of other FLARM-equipped aircraft and
calculated separately for 20 sectors, 18° each.
A range analysis should be done after installation and then as part of the annual
maintenance (see Section 9).
POWERFLARM
FUSION USER AND
MAINTENANCE
MANUAL
Date: 2020-11-10
Version: 1.0
Page: 24 of 49
Document Number:
FTD-078
