Specifications

Compatible Devices TR-7Ui Series: 74Ui / 76Ui / 73U (including S Type)
Storage Capacity
Communication
Interfaces
Communication
Time
Power
Battery Life
Dimensions
Weight
Operating
Environment
50
TR-5i Series: TR-51i / 52i / 55i-TC / 55i-Pt / 55i-V / 55i-mA / 55i-P
Discontinued: VR-71, TR-71Ui/72Ui/77Ui, TR-71S/72S, TR-71U/72U,
TR-51S/52S, TR-51A/52, RTR-51/51A/52/52A/52Pt/53/53A, RVR-52A
(including H Type and L Type)
Up to 256,000 readijngs
When downloading from units filled to logging capacity:
- 16 units of TR-71Ui/72Ui/77Ui
- 10 units of TR-73U/76Ui
- 7 units of TR-74Ui
- 16 units of TR-51i/52i
- 15 units of TR-55i
When downloading from units of any type containing small amounts of
data, it can store and manage up to 250 download sessions.
<Between TR-57DCi - Data Logger(s)>
TR-5i/5S/5 Series, RTR-5 Series:
Optical Communication
TR-7Ui Series, TR-5i Series:
Infrared Communication: IrPHY 1.2 low power (*1)
TR-7Ui/7U/7S Series, VR-71:
Serial Communication: RS-232C (*2)
<Between TR-57DCi - PC>
USB Communication
Serial Communication: RS-232C (*3)
TR-7Ui Series
- Via infrared communication (8000 readings x 2ch) : About 55 sec.
- Via infrared communication (8000 readings x 3ch) : About 63 sec.
- Via infrared communication (8000 readings x 4ch) : About 77 sec.
TR-5i Series
- Via optical communication: About 24 sec.
- Via infrared communication: About 55 sec.
AAA Alkaline Battery LR03 x 2, AAA Ni-MH Battery x 2,
USB bus power, AC adaptor AD-06A1 or AD-06C1
About 100 days at 1 hour of daily use (*4)
H 125 mm x W 58 mm x D 25.8 mm
(excluding protrusions)
Approx. 90 g
Temperature: 0 to 50 °C
Humidity: 90 %RH or less (no condensation)
