Downloading Via Infrared Communication - T&D TR-57DCi User Manual

Downloading via Infrared Communication

1.
In the Main Menu, open [
on the TR-57DCi Unit.
2.
Under [Sel.Logger], select the Data Logger Series from which you wish
to download data.
For the TR-7Ui Series, just select "TR-7i". For the TR-5i Series, after
selecting "TR-5i", then select the period of data to be downloaded.
* When using the <
communication will be carried out according to the same settings as the previous
session.
3.
After adjusting the arrow to [Execute] and pressing the Operation Dial,
place the infrared port of TR-57DCi and data logger face-to-face. (See
p.23)
Gather Data] or press the < Ir>button
Ir>button to download data, this window will not appear and
29
