Introduction

1 Introduction
Information:
B&R makes every effort to keep documents as current possible. The most current versions can be
downloaded from the B&R website (www.br-automation.com).

1.1 Manual history

Version Date
1.10 May 2020
1.02 April 2020
1.01 November 2019
1.00 September 2019

1.2 Information about this document

This document is not intended for end customers! The safety guidelines required for end customers
must be incorporated into the operating instructions for end customers in the respective national lan-
guage by the machine manufacturer or system provider.

1.2.1 Organization of notices

Safety notices
Contain only information that warns of dangerous functions or situations.
Signal word
Danger!
Warning!
Caution!
Notice!
General notices
Contain useful information for users and instructions for avoiding malfunctions.
Signal word
Information:

1.2.2 Guidelines

European dimension standards apply to all dimension diagrams.
All dimensions in mm.
Unless otherwise specified, the following general tolerances apply:
Nominal dimension range
Up to 6 mm
Over 6 to 30 mm
Over 30 to 120 mm
Over 120 to 400 mm
Over 400 to 1000 mm
6
Comment
Content-related changes and corrections:
•
Added information regarding derating.
• Updated description of the reset button.
• Added information regarding permissible lengths of POWERLINK and Ethernet connections.
• Added optional accessory 6ACCRPP2.0001-000.
• Editorial changes.
Updated system requirements.
Corrected power consumption of the 7.0" and 15.6" variants in the technical data.
First edition
Description
Failure to observe these safety guidelines and notices will result in death, severe injury or substantial damage to property.
Failure to observe these safety guidelines and notices can result in death, severe injury or substantial damage to property.
Failure to observe these safety guidelines and notices can result in minor injury or damage to property.
Failure to observe these safety guidelines and notices can result in damage to property.
Description
Useful information, application tips and instructions for avoiding malfunctions.
General tolerance per
DIN ISO 2768 medium
±0.1 mm
±0.2 mm
±0.3 mm
±0.5 mm
±0.8 mm
Power Panel C50 User's manual V1.10
