Input Specifications - M-system 47DV Series Manual

Protected time duration: No limit

INPUT SPECIFICATIONS

INPUT CODE: 1 (DC voltage)
MEASURING OPERATIONAL
TYPE ID
RANGE
1 – 5V
±5V
±20V
±200V
INPUT CODE: 2 (DC current)
MEASURING OPERATIONAL
TYPE ID
RANGE
4 – 20mA
0 – 20mA
±20mA
±200mA -240 – +240mA
DC OUTPUT SIGNAL SPECIFICATIONS
VOLTAGE OUTPUT
OUTPUT
TYPE ID
RANGE
–
0 5V
±5V
±10V
CURRENT OUTPUT
OUTPUT
TYPE ID
RANGE
–
0 20mA
–
4 20mA
I/O OPTIONS
■ Event Trigger Input: Dry contact or NPN open collector
Input current: ≤ 3 mA
Sensing: 6 V
Contact detecting: ≤ 1.5 V at ON; ≥ 3 V at OFF
Signal ID and Details
S-TMR: Startup Timer
Measuring starts in the predetermined time after detecting
the signal turning on.
TIMING: Timing
Used for various timing hold functions
ZERO: Forced Zero
Forced Zero and tare adjustment are externally controlled
when ZERO signal is turned on/off.
HOLD: Hold data
Reading measured signal stops and the last
value is held when HOLD signal is turned on.
RESET: Reset data
The device is reset when RESET signal is turned on.
■ Alarm Output: Relay contact
http://www.m-system.co.jp/
INPUT
RANGE IMPEDANCE
0.6 – 5.4V 1M Ω minimum
-6 – +6V 1M Ω minimum
-24 – +24V 1M Ω minimum
-240 – +240V 1M Ω minimum
INPUT
RANGE IMPEDANCE
2.4 – 21.6mA 10Ω
-2 – +22mA 10Ω
-24 – +24mA 10Ω
1Ω
OPERATIONAL LOAD
RANGE RESISTANCE
– minimum
-0.5 +5.5V 2000Ω
-6 – +6V 4000Ω minimum
– minimum
-12 +12V 8000Ω
OPERATIONAL LOAD
RANGE RESISTANCE
– maximum
-2 +22mA 400Ω
– maximum
2.4 21.6mA 400Ω
Rated load: 250 V AC @ 3 A (cos ø = 1)
30 V DC @ 3 A (resistive load)
Maximum switching voltage: 250 V AC, 30 V DC
Maximum switching power: 750 VA, 90 W (resistive load)
Minimum load: 5 V DC @ 10 mA
Mechanical life: ≥ 5 × 10
■ Alarm Output: Photo MOSFET relay
Rated load: 120 V AC/DC @ 80 mA (resistive load)
ON resistance: 25 Ω
Permissible loss: 250 mW
■ Network Interface
Transmission: Half-duplex, asynchronous, no procedure
Interface: Conforms to TIA/EIA-485-A
Max. transmission distance: 500 meters
Baud rate: 1.2 – 38.4 kbps
Max. number of nodes: 31 (except the master)
Protocol: Modbus RTU
Parity: None, odd or even
Stop bit: 1 bit, 2 bits
Node address: 1 to 247
Media: Shielded twisted-pair cable (CPEV-S 0.9 dia.)
Terminating resistor: Built-in (Connect across T2 - T3, when
the unit is the end of the line)
■ BCD Output + Control Signals
• Input Signals: Dry contact or NPN open collector
Input current: ≤ 3 mA
Sensing: 6 V
Contact detecting: ≤ 1.5 V at ON; ≥ 3 V at OFF
Signal ID and Details
REQ: Request BCD data
Valid data in approx. 30 msec. after detecting
the signal's rising edge
MIN_REQ: Request Minimum reading data
Valid data in approx. 30 msec. after detecting
the signal's rising edge
MAX_REQ: Request Maximum reading data
Valid data in approx. 30 msec. after detecting
the signal's rising edge
HOLD: Hold data
Reading measured signal stops and the last value
is held when HOLD signal is turned on.
RESET: Reset data
All BCD data turn off when RESET signal is turned
on.
• Output Signals: NPN open collector
Max. load voltage: 24 V DC
Max. load current: 10 mA
Saturation voltage: ≤ 0.3 V
Leakage current: ≤ 500 μA
Signal ID and Details
DATA (Do 11...Do 68): BCD Output data in 6 digits
Do 1x = LSD ... Do 6x = 6th LSD
47DV SPECIFICATIONS
MODEL: 47DV
6
cycles (rate 180 cycles/min.)
ES-9501 Rev.16 Page 3/13
