HD IP Camera

Recording Menu

For recording to be available the HD IP Camera must have the recording option included. If this
option is included the camera will be fitted with a 32GByte SD card. The SD card is located beneath
a cover plate. For access to the SD card, remove the two T5 screws, cover plate and gasket.
SD card cover plate
The SD Card has a capacity of 32GBytes, this offers 17 hours of continuous recording at a total IP bit
stream of 4Mb/s or 34 hours at 2Mb/s, etc. If recording capacity is achieved there is a user option to
either stop recording or overwrite. The recording web page menu is shown below.
Note: Recording is temporarily paused during activity on the camera's web interface.
Timed Recording
There are 4 options for timed
recordings, these are; Off,
Continuous, Once and Daily.
Off = No recording takes place.
Continuous = Recording
Continuously.
Once = Record once when the
start time is reached and record
for the set duration.
Daily = Record daily starting when
the start time is reached and
record for the set duration.
visualengineering.co.uk
Visual Engineering
Video solutions. Integrated
August 2020
Press down to release
the SD card
