8 English
Manual Indicator (№9 рiс.2) will turn off.
10. To turn the instrument off, press On/Off button (№2 рис.2).
ROTATION SPEED CHANGE
The laser beam is more visible when the rotating speed is slow. Change the
speed of the rotating laser head by pressing the Speed button. The default
speed is 600 rpm. By pressing the Speed button (№13 рiс.2) you can change
the speed as follows: 0-120-300-600 rpm.

SCAN FUNCTION

The Scan function is used to limit the area covered by the laser beam, for
safety reasons or to improve visibility and sensitivity. The smaller the scanned
segment, the better it is visible. The default mode is 360°, which is provided
by the horizontal or inclined beam throughout the work area or room. The
Scan button (№4 рiс.2) changes the mode as follows: 0°- 10°- 45°-90°- 180° .
1. Press the Scan button (№4 рiс.2) to change the scan width.
2. The scan mark can be accurately positioned using the Clockwise (№5
рис.2) and Counterclockwise rotation buttons (№12 рис.2).
5

LASER DETECTOR

Laser detector increases the measurement range of the tool. Use the detector
when the laser beam is poorly visible, e.g. outdoor or in bright light. When
operating with the rod, set the detector on the rod with the help of mount.
1. Sound On/Off
2. ON/OFF power
3. Line over the Zero level Indicator
4. LED indicator - Zero level
5. Line below the Zero level Indicator
6. LCD display
7. Detector sensor
8. Backlight On/Off
9. Selection of detection accuracy
10. Accurate mode symbol
11. On/Off backlight symbol
12. On/Off sound symbol
13. Power indicator
