Planar LookThru LO552 Series User Manual page 9

Command
Setting
Code
Advanced CMSFLSAG 212
Color Flag
Allow Pop Up OSD.ALLOW. 1300
Messages POPUP
Aspect Ratio ASPECT 500
Audio Input AUDIO.INPUT 1003
Audio Select AUDIO.ZONE 1007
Auto Power AUTO.ON 1407
On
Auto Scan SOURCE.SCAN 105
Sources
Balance AUDIO.BALANCE 1000
Planar LookThru Display Series RS232 User Manual
020-1381-00B
Modifiers
? Mod 1: Zone String
0 = ZONE.1
1 = ZONE.2
2 = ZONE.3
3 = ZONE.4
255 = CURRENT
Mod 2: Gamut
0 = REC709
1 = SMPTEC
2 = EBU
5 = USER
6 = AUTO
255 = CURRENT
Mod 3: Color
Point
0 = RED.X
1 = RED.Y
2 = GREEN.X
3 = GREEN.Y
4 = BLUE.X
5 = BLUE.Y
6 = CYAN.X
7 = CYAN.Y
8 = MAGENTA.X
9 = MAGENTA.Y
10 = YELLOW.X
11 = YELLOW.Y
12 = WHITE.X
13 = WHITE.Y
=?+- 0 = NO
1 = YES
=?+- Zone 0 = AUTO
0 = ZONE.1 1 = 16X9
1 = ZONE.2 2 = 4X3
2 = ZONE.3 3 = FILL
3 = ZONE.4 4 = NATIVE
253 = ALL.INPUT 5 =
254 = ALL LETTERBOX
254 = ALL.ZONE
255 = CURRENT
[None =
CURRENT]
? Source
0 = OPS
1 = HDMI.1
2 = HDMI.2
3 = HDMI.3
4 = HDMI.4
5 = DP
=?+- Zone
0 = ZONE.1
1 = ZONE.2
2 = ZONE.3
3 = ZONE.4
=?+- 0 = OFF
1 = ON
=?+- 0 = OFF
1 = ON
=?+- 0-100
Example
No [Zone 1 REC709 red x coordinate is
achievable]
CMSFLAG(ZONE.1, REC709, RED.X)?
CMSFLAG(ZONE.1 REC709 RED.X):""
[Zone 2 EBU blue y coordinate is not
achievable]
CMSFLAG(ZONE.2, EBU, BLUE.Y)?
CMSFLAG(ZONE.2 EBU BLUE.Y):"*"
No OSD.ALLOW.POPUP=YES
OSD.ALLOW.POPUP:YES
No [For Zone 1] ASPECT(ZONE.1)=AUTO
ASPECT(ZONE.1):AUTO
[For the current zone] ASPECT=16X9
ASPECT:16X9
No AUDIO.INPUT?
AUDIO.INPUT:HDMI.1
No AUDIO.ZONE=ZONE.1
AUDIO.ZONE:ZONE.1
Yes AUTO.ON=ON
AUTO.ON:ON
No SOURCE.SCAN=ON
SOURCE.SCAN:ON
No AUDIO.BALANCE=50
AUDIO.BALANCE:50
RS232 Codes
Notes
See Main -> Advanced
Settings -> Advanced Color
In some cases, the target
color coordinates may not be
achievable. In this case, "*"
will be returned by this
command. Otherwise, an
empty string will be returned.
See Main -> Advanced
Settings -> Menus and
Messages -> Allow Pop Up
Messages
See Main -> Image Adjust ->
Aspect Ratio
Returns the input source in the
zone currently playing audio,
as chosen by Audio Select
See Main -> Audio -> Audio
Select
See Main -> Advanced
Settings -> Power -> Auto
Power On
See Main -> Inputs and
Views -> Auto Scan Sources
See Main -> Audio -> Balance
Page | 9
