- Page 1 Product Specification - LC12 High-Bright Monitor Document Number: 023-0284-01 Revision: A Title: Product Specification: LC12 High- Bright AMLCD Monitor Page 1 of 24 Document Number: 023-0284-01 Revision: A...
-
Page 2: Table Of Contents
8.0 REGULATORY AGENCY REQUIREMENTS ..........................19 Safety Certification......................19 CE Marking (Declaration according to ISO/IEC Guide 22 and EN45014)...... 19 RFI Emission Certification ....................20 Title: Product Specification: LC12 High-Bright Monitor Page 2 of 24 Document Number: 023-0284-01 Revision: A... - Page 3 Failure Definition......................21 10.0 DESCRIPTION OF WARRANTY..............................21 11.0 SUPPORT AND SERVICE ................................... 22 12.0 GLOSSARY OF TERMS AND ABBREVIATIONS ........................22 13.0 REVISION HISTORY.................................... 24 Title: Product Specification: LC12 High-Bright Monitor Page 3 of 24 Document Number: 023-0284-01 Revision: A...
-
Page 4: Introduction
Only the first 640 pixels will be displayed. IBM VGA is a registered trademark of International Business Machines Corporation VESA is a registered trademark of Video Electronics Standards Association. Title: Product Specification: LC12 High-Bright Monitor Page 4 of 24 Document Number: 023-0284-01... -
Page 5: Basic Construction
The DC power input connector is a chassis mounted 2-pin "MAT?N?LOK" style connector (AMP 1-480699-0 or equivalent) with pin contacts at the rear of the Monitor. Connections are insulated to insure no accidental contact. Title: Product Specification: LC12 High-Bright Monitor Page 5 of 24 Document Number: 023-0284-01... -
Page 6: Lcd Controller Board
External horizontal and vertical image positioning control(s) are provided to accommodate for the undefined delay between sync and video data edge referred to as Front Porch / Back Porch in Figure 9. Title: Product Specification: LC12 High-Bright Monitor Page 6 of 24 Document Number: 023-0284-01... -
Page 7: Environmental
60°C [140°F] Solar Loading The Monitor is useable in an environment consisting of a 50 C ambient air temperature and the following input solar power. Title: Product Specification: LC12 High-Bright Monitor Page 7 of 24 Document Number: 023-0284-01 Revision: A... -
Page 8: Altitude
Altitude Maximum operating altitude is 3,000 meters [9,850 feet]. Maximum shipping and storage altitude is 12,000 meters [39,400 feet]. Mechanical Vibration and Shock Note: Tests performed with unpackaged Monitors are mounted in a Planar approved rigid retaining fixture. 3.4.1 Vibration Non-Operating (sinusoidal): 10-200 Hz, 0.9g acceleration, 120 seconds per... -
Page 9: Video Signal Input Requirements
Coaxial cable is provided for video signal line(s) to match impedances and for EMI attenuation. The video input signal will have a range of 0-mv to 714-mv (maximum) Title: Product Specification: LC12 High-Bright Monitor Page 9 of 24 Document Number: 023-0284-01... - Page 10 Figure 5. Rise / Fall Time 4.2.2 Synchronization Sync pulses for horizontal and vertical are TTL levels. Figure 8 defines the levels and drive current capabilities. Title: Product Specification: LC12 High-Bright Monitor Page 10 of 24 Document Number: 023-0284-01 Revision: A...
- Page 11 Monitor Sense Lines. The Monitor will indicate to the source that it is a "color display" when Monitor Sense Line 1 (Pin 11) is Title: Product Specification: LC12 High-Bright Monitor Page 11 of 24...
-
Page 12: Signal Quality
1.813-µsec to 3.813-µsec. The Monitor will "sync" to the specified format vertical frequencies between 60Hz?72Hz without adjustment. Absence of Horizontal and/or Vertical Sync will not damage the Monitor nor violate EMI radiation limits specified herein. Title: Product Specification: LC12 High-Bright Monitor Page 12 of 24 Document Number: 023-0284-01 Revision: A... -
Page 13: Video Signal On-Off Sequences
15.254 ms 480 lines 12.480 ms 600 lines 13.599 ms 768 lines Vertical Sync Polarity Note: VGA border is not included in the Active Display time described above. Title: Product Specification: LC12 High-Bright Monitor Page 13 of 24 Document Number: 023-0284-01 Revision: A... - Page 14 Performance is acceptable if characters as defined section 1.2.1 are legible. Missing row or columns at edge of display is acceptable as long as characters remain legible. Title: Product Specification: LC12 High-Bright Monitor Page 14 of 24 Document Number: 023-0284-01...
-
Page 15: Dc Power Input Requirements
Refer to Figure 12 for required current profile characteristics at “power–up” conditions. The Monitor is not damaged by input voltages ranging from 0-vdc to 12.4-vdc". Title: Product Specification: LC12 High-Bright Monitor Page 15 of 24 Document Number: 023-0284-01... -
Page 16: Power On-Off Sequences
Display contrast is a relationship between luminance levels and the ability to perceive a luminance difference. It is expressed as a ratio of ON white – luminance to OFF black background luminance generated by the display. Title: Product Specification: LC12 High-Bright Monitor Page 16 of 24 Document Number: 023-0284-01... -
Page 17: Display Uniformity
800 (H) x 600 (V) (1 full color pixel = R + G + B dots) Pixel Pitch: 0.3075mm [0.012in] horizontal x 0.3075mm [0.012in] vertical Pixel Arrangement: R,G,B vertical stripe Title: Product Specification: LC12 High-Bright Monitor Page 17 of 24 Document Number: 023-0284-01 Revision: A... -
Page 18: Display Cosmetics
Qty Allowed Size Separation >.020” .010 < D <.020” Circular Dark Defects .005” < D < - .010” .100” Contamination Not cause for <.005” rejection Title: Product Specification: LC12 High-Bright Monitor Page 18 of 24 Document Number: 023-0284-01 Revision: A... -
Page 19: Regulatory Agency Requirements
Member States relating to electromagnetic compatibility is based on compliance with the following harmonized standards: Electromagnetic Emissions EN 55022 Class A: 1994 Title: Product Specification: LC12 High-Bright Monitor Page 19 of 24 Document Number: 023-0284-01 Revision: A... -
Page 20: Rfi Emission Certification
9.0 Reliability Design Workload The Monitor is capable of operating 24 hours a day, 365 days a year under the specified environmental conditions per section 3.1. Title: Product Specification: LC12 High-Bright Monitor Page 20 of 24 Document Number: 023-0284-01 Revision: A... -
Page 21: Critical Failures
Buyer's failure to properly store, install, operate, handle or maintain the Goods are not within this warranty. Repair or replacement of Goods is Seller’s sole obligation and Buyer's exclusive remedy for all Title: Product Specification: LC12 High-Bright Monitor Page 21 of 24... -
Page 22: Support And Service
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE 11.0 Support and service Planar is a US company based in Beaverton, Oregon and Espoo, Finland with a worldwide sales distribution network. Full application engineering support and service are available to make the integration of Planar displays as simple and quick as possible for our customers. - Page 23 Shades of Gray: A division of the gray scale from black to white into a series of discrete luminance shades with a square-root-of-2 difference between successive shades. Title: Product Specification: LC12 High-Bright Monitor Page 23 of 24 Document Number: 023-0284-01...
-
Page 24: Revision History
White: The common usage word for high-luminance achromatic colors. XGA: Extended Graphics Adapter 13.0 Revision History DATE PAGE DESCRIPTION OF CHANGE 14 Jan. 05 First release S.Vahlsing Title: Product Specification: LC12 High-Bright Monitor Page 24 of 24 Document Number: 023-0284-01 Revision: A...
