- Page 1 LC1502R SERIES USER’S GUIDE www.planar.com...
- Page 2 A Planar part number will be modifi ed with an “LF” suffi x designation to indicate RoHS compliance, as shown on the part number label affi xed to the display and on the box containing the display.
- Page 3 LC1502R User’s Guide (020-0315-02B)
- Page 4 LC1502R User’s Guide (020-0315-02B)
-
Page 5: Table Of Contents
Table of Contents Usage Notice Safety and Use Precautions ......... 6 Introduction About the LC1502R . -
Page 6: Usage Notice
Usage Notice Warning - To prevent the risk of fire or shock hazards, do not directly expose this product to rain or moisture. Warning - Please do not open or disassemble the product as this may cause electric shock. Safety and Use Precautions Follow all warnings, precautions and maintenance as recommended in this User's Manual to maximize the life of your monitor. -
Page 7: Introduction
Introduction About the LC1502R The LC1502R is a high performance monitor designed for demanding applications. The monitor consists of a 15" diagonal flat panel liquid crystal display (LCD) housed in a metal enclosure with an integrated ambient light sensor to facilitate automatic brightness control. Features include: •... -
Page 8: Package Overview
Package Overview VGA Signal Cable Quick Start Guide LC1502R User’s Guide (020-0315-02B) -
Page 9: Installation
Installation Product Overview • Front View • Rear View LC1502R User’s Guide (020-0315-02B) -
Page 10: Connector Descriptions
Connector View Connector Descriptions 1. Video Interface Connector Standard D-sub Analog; 15-pin D-sub connector 2. Power Input Connector Connector type: 4-pin mini DIN socket Manufacturer: Singatron Enterprise Co. (Taiwan) Part Number: 2MJ-0402A120 Mating Connector: 2MP-0402 series Power Connector Pin Configuration Description +12V DC +12V DC... -
Page 11: Mounting
M4 threaded holes are provided in the sides of the monitor housing for mounting purposes. The blind holes will accommodate 10 mm long screws. See the mechanical outline drawing 076-0579-xx at www.planar.com/support for details. Planar does not supply mounting fasteners. LC1502R User’s Guide... -
Page 12: Start Your Installation
Start Your Installation Connecting the Display (Figure 1.0) To configure the monitor, please refer to the following figure and procedures. 1. Be sure the computer or video source is turned off. 2. Connect the 12V DC power(1.0). During initial turn on with no video applied, the display will automatically power on with a self test pattern displayed. -
Page 13: User Controls
User Controls Control Buttons Displays the OSD menus 1. Decreases the value of the adjustment items. 2. Decreases the minimum brightness limit of the display image. 1. Increases the value of the adjustment items. 2. Increases the minimum brightness limit of the display image. -
Page 14: How To Use The Osd Menus
How to Use the OSD Menus 1. Press the "Menu" button to pop up the on-screen menu and to select between the four main menus. 2. Choose the adjustment items by pressing the "Select/Auto" button. 3. Adjust the value of the adjustment items by pressing the "+" or "-" button. 4. -
Page 15: On-Screen Display Menus
On-Screen Display Menus SUB MENU FUNCTION DESCRIPTION MAIN MENU 0-100 Adjusts the Minimum brightness limit of the display. MIN BRIGHTNESS 0-100 Adjusts the contrast of the image. CONTRAST CLOCK 0-100 Adjusts the clock to obtain an optimum image.. LCD ADJUSTMENT PHASE 0-63 Adjust the sampling timing for converting the ana-... -
Page 16: Brightness Control
Brightness Control The brightness of the monitor may be controlled automatically or manually, and the minimum brightness is adjustable. By default, the monitor is configured for automatic brightness control with a minimum brightness setting of approximately 250 cd/m Automatic Brightness Control In automatic brightness control mode, a photo sensor mounted on the front of the display measures the ambient lighting condition (the illuminance). -
Page 17: Manual Brightness Control
The schematic below is a reference design for the user to install the photo sensor remotely from the display. Reference Design for Remote Photo Diode Brightness Control Manual Brightness Control In manual brightness control mode, an externally supplied voltage determines the monitor brightness. To use manual brightness control mode instead of the default automatic brightness control mode: 1. -
Page 18: Minimum Brightness Limit
The graph below shows the typical factory set response to the DIM_INPUT voltage when in manual brightness control mode. Figure 2 Minimum Brightness Limit The factory set minimum brightness is approximately 300 cd/m . In most applications the factory set- ting is desired to maintain the widest dimming range possible. -
Page 19: Maximum Brightness Mode
To change the minimum brightness limit, one of three basic methods can be used: 1. If one wishes to set an approximate minimum brightness, the above graph may be used. For instance, to set the minimum to approximately 500 cd/m , set the minimum brightness limit to an OSD setting of 60. -
Page 20: Specifications
Specifications Electrical and Optical Parameter Units Conditions/Notes Input Power, Voltage 11.4 12.0 12.6 volts Input Power, Current 3.95 amps Monitor Power Consumption 47.4 49.2 watts Logic High volts For logic inputs Logic Low -0.4 volts For logic inputs DIM input voltage volts Analog input Maximum White Luminance... -
Page 21: Mechanical And Environmental
Mechanical and Environmental Parameter Specification Operating Temperature -10 to 60°C Operating Humidity 30 to 85% RH, non-condensing Storage Temperature -20 to 65°C Storage Humidity 10 to 85% RH, non-condensing Active Area Surface Treatment Anti-glare, 3H hard coating Weight < 3 kg Mechanical Shock Half sine wave, 30g, 11ms, 3 shocks per axis... -
Page 22: Reliability And Life
Reliability and Life Parameter Specification Mean Time Between Failures 20k hours at 25°C, 90% confidence level Time to 50% brightness decay from initial brightness 40k hours minimum at 25°C, operating continuously at maximum brightness Safety and Regulatory Certifications FCC Certification FCC Part 15, Subpart B, Class B - Conducted and Radiated Tests CE Certification Emission... -
Page 23: Available Options
The LC1502R requires a 12VDC power input. Many users will have the required 12VDC available in their existing system. Alternatively, a power supply that is appropriately rated for the LC1502R is available from Planar. The supply is available with the AC power cord configured with either a European plug or a US plug. -
Page 24: Cooling Kit
Cooling Kit For outdoor applications, a cooling kit may be desired to prevent excessive heating of the LCD display. In direct sunlight, the front surface of the display (the LCD cell) may reach temperatures well above the ambient temperature. Possible effects of extreme surface temperatures include: •... -
Page 25: Touch Screens
3mm Set Up: 1. Refer to Planar mechanical outline drawing for the mounting hole locations. 2. Connect the USB cable from display to USB port on computer. 3. Power on computer and install the touchscreen driver found on the provided CD. Follow instructions to calibrate the touch screen. -
Page 26: Appendix
If you are experiencing trouble with the LCD display, refer to the following. If the problem persists, please contact your local stat or visit Planar Support at www.Planar.com/support. See support contact information on rear cover. For all video image problems, first try using the Auto-Adjustment in the OSD menu Problem: No image appears on screen. -
Page 27: Mechanical Outline
Properties" in the Control Panel folder. Faint Horizontal Dark Lines Across the Screen This display is directly backlit by cold cathode fluorescent lamps. Slight brightness nonuniformity is normal. Mechanical Outline See mechanical outline drawing on www.planar.com/support LC1502R User’s Guide (020-0315-02B) -
Page 28: Support And Service
Support and Service Planar is a US company based in Beaverton, Oregon and Espoo, Finland with a worldwide sales distribution network. Visit Planar at http://www.planar.com/support for product registration, operations manuals, line drawings, touch screen drivers, warranty information and access to Planar’s Technical Library for online troubleshooting. - Page 29 Email: IntlTech_Support@Planar.com Hours: M-F, 7am-4pm CET © 2006 Planar Systems, Inc. 11/06 Planar is a registered trademark of Planar Systems, Inc. Other brands and names are the property of their respective owners. Technical information in this document is subject to change without notice.
