Planar LX1501PTI User Manual

Mariner ip-65 touch monitors
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Mariner
LX0801PTI/ LX1201PTI/ LX1501PTI
IP-65 Touch Monitors
USER'S GUIDE
www.planar.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LX1501PTI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Planar LX1501PTI

Summary of Contents for Planar LX1501PTI

  • Page 1 Mariner LX0801PTI/ LX1201PTI/ LX1501PTI IP-65 Touch Monitors USER’S GUIDE www.planar.com...
  • Page 2 Recycle or dispose in accordance with local, state, or federal Laws. For more information, contact the Electronic Industries Alliance at HYPERLINK “http://WWW.EIAE.ORG” For lamp specifi c disposal information check WWW.LAMPRECYCLE.ORG. LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0982-00A)

  • Page 3: Table Of Contents

    Front Panel Controls ...17 Turning the Monitor On and Off ...18 Using the Touchscreen ...18 Navigating the Touchscreen ...18 Cleaning the Monitor ...18 Appendix Troubleshooting the Monitor ...20 Specifi cations ...21 LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0982-00A)
  • Page 4 Direct 8-30 VDC Power Scheme ... 27 Addendum G ... 28 RAM Mount for LX0801PTI ... 28 Addendum H ... 29 Frequently Asked Questions ... 29 Support and Service ... 30 LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0982-00A)

  • Page 5: Usage Notice

    In a Watercraft or Vehicle: • The monitor should be visible to the driver only if it is used for navigation, or system control. Care should be taken to ensure distraction does not occur. •...

  • Page 6: Introduction

    8-32 VDC power aboard the watercraft. The metal enclosure is IP-65, designed to withstand liquid and dust intrusion. An optional cosmetic bezel is included with each monitor. Front Views: AMLCD TFT with Touchscreen Auxiliary power switch Brightness adjust/auto sync buttons LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0982-00A)

  • Page 7: Rear View With Connector Information

    VGA: The VGA connector located inside the monitor is waterproof. The connector style is standard 15-pin VGA. DC Power Connector Only: LTWCD-07BFFA-LL 7001 DC Cable Assembly: LTWCD07AFFM-LL7Axx (01, 02, ... 99 meter length) LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0982-00A)

  • Page 8: Features

    The monitor supports • LX0801PTI is 800 x 600 SVGA (native) and 640 x 480. • LX1201PTI and LX1501PTI are 1024 x 768 XGA (native), 800 x 600 and 640 x 480. • The monitor’s IP-65 enclosure protects from splashed water and dust. It is designed to withstand shock and vibration for greater endurance and reliability.

  • Page 9: Package Overview

    (Bezel is attached for shipping.) Note: Mounting hardware (M4 Screws), mounting brackets, power supply, USB and video cables are sold separately. Software drivers can be downloaded from www.Planar.com/downloads LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0982-00A) Quick Start Guide 2M Power Cord...

  • Page 10: Installation

    Installing the monitor consists of three steps: Attaching the monitor using one of the mounting interfaces built into the monitor’s enclosure. Connecting the monitor to the computer and power source. Installing the touchscreen driver software. LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0982-00A)

  • Page 11: Step 1 - Mounting The Monitor

    Step 1 - Mounting the Monitor The back and sides of the monitor include mounting points that you can use to mount the monitor as your installation requires. Mounting holes on the LX0801PTI, LX1201PTI and LX1501PTI allow the monitor to be mounted : •...

  • Page 12: Step 2 - Connecting The Monitor

    Note: For best results, adjust the display mode of the computer to a resolution of 800 x 600 (LX0801PTI) or 1024 x 768 (LX1201PTI and LX1501PTI) and a refresh rate of 60 Hz. LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0982-00A)

  • Page 13: Step 3 - Irtouch Software Installation

    Step 3 - IRtouch Software Installation IMPORTANT – Do not plug in the touchscreen yet! Install the driver fi rst. Run IRtouch driver setup Accept user agreement 3. Install in default location LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0982-00A)
  • Page 14 Click continue, you can trust Planar and IRtouch Click on Finish Attach the Planar monitor to the system or install the computer to a docking station. Attach the USB cable. After the USB cable from the monitor is attached to the computer it will recognize the touchscreen for the fi...
  • Page 15 7. Continue Click Finish Click the IRtouch icon located on your desktop to calibrate the touch monitor. Click Calibrate LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0982-00A)
  • Page 16 When used in rugged environments with software written for touchscreens, you may fi nd it easier to use the ‘click on release’ radio button. Beep You can set the computer to beep on touch activation if needed. LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0982-00A)

  • Page 17: User Controls Front Panel Controls

    This is because the vast majority of marine installations utilize a circuit breaker to turn power on/off to electrical devices. LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0982-00A) FUNCTION Turns the CPU off and sends signal to host PC through power cable.

  • Page 18: Turning The Monitor On And Off

    • Always turn off the monitor before cleaning. • Clean the touchscreen with a dry soft cloth. If this does not clean the screen adequately, preferably use Sparkle or Glass X cleaners. LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0982-00A)
  • Page 19 (that does not contain ammonia) applied to the cloth and not to the display. • Clean the monitor housing with a soft cloth moistened with mild detergent. • Never apply abrasive cleaners, waxes or solvents to the monitor. LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0982-00A)

  • Page 20: Appendix

    Initiate an auto-sync to solve the problem. Problem: The monitor does not appear to respond to the touchscreen • Make sure the USB cable to the computer is securely connected at both ends. LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0982-00A)

  • Page 21: Specifi Cations

    Reverse Polarity Protection Regulatory and Safety Enclosure Including Front Bezel Input/Outputs Weight with Plastic Bezel LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0982-00A) LX1501PTI - 15" Full Color TFT AMLCD 304 (w) x 228 (h) mm 15" (381 mm) 262 K (6 bit/color);...
  • Page 22 Reverse Polarity Protection Regulatory and Safety Enclosure Including Front Bezel Input/Outputs Weight with Plastic Bezel LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0982-00A) LX1201PTI - 12.1" Full Color TFT AMLCD 246 (w) x 184.5 (h) mm 12.1" (307 mm) 262 K (6 bit/color);...
  • Page 23 Reverse Polarity Protection Regulatory and Safety Enclosure Including Front Bezel Input/Outputs Weight with Plastic Bezel LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0982-00A) LX0801PTI - 8.4" Full Color TFT AMLCD 170 (w) x 127 (h) mm 8.4" (213 mm) 262 K (6 bit/color);...

  • Page 24: Addendum A

    Addendum A An interconnection to the host PC with USB can be exploited by the customer to create an OSD. Planar has utilized a powerful Pixelworks video IC to enable this functionality should customers desire increased control functions. Planar does not provide the programming to do this.

  • Page 25: Addendum C

    FOR TILTING AND LOCK DOWN MOUNTING. SEE 135.0 CAD DATA. POSSIBLE MATING CABLES LTWUB-20BFM-A7A02 (2m LONG) LTWUB-20BFM-A7A05 (5m LONG) LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0982-00A) 247 (TOUCH SCREEN OPENING) 275.0 100.0 DEPTH 75.0 VGA CONNECTOR TOUCH SCREEN...

  • Page 26: Addendum E

    TOUCH SCREEN CONNECTOR USB TYPE B LTWUB-20PMFP-SC8002 POSSIBLE MATING CABLES LTWUB-20BFM-A7A02 (2m LONG) LTWUB-20BFM-A7A05 (5m LONG) LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0982-00A) 307 (TOUCH SCREEN OPENING) 336.0 100.0 VGA CONNECTOR LTWHDB-15PFFP-SA8001 POSSIBLE MATING CABLES LTWHDB-15AMMM-SL7A02 (2m LONG)

  • Page 27: Addendum F

    Direct 8-30 VDC Power Scheme Wire Color Blue Yellow Green Orange White LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0982-00A) Defi nition 8-30 VDC to Invertor 8-30 VDC to Invertor 8-30 VDC to Video Board Ground to Invertor Ground to Video Board...

  • Page 28: Addendum G

    Addendum G RAM Mount for LX0801 PTI 7.35 REF. 0.22 0.91 RAD. 120 DEGREES 3 PLACES 1.50 2.49 1.19 2.44 REF. LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0982-00A)

  • Page 29: Addendum H

    Addendum H Frequently Asked Questions Q1: I want to be able to turn power off to the monitor on/off with a switch. I do not want the monitor to be in stand-by power mode because it draws power; and, I don’t want to use a Vehicle Battery Voltage Shutdown Timer mentioned on page 12 of this manual.

  • Page 30: Support And Service

    Tel: +358-9-420-01 Hours: M-F, 7am - 4pm CET © 2009 Planar Systems, Inc. 2/09 Planar is a registered trademark of Planar Systems, Inc. Other brands and names are the property of their respective owners. Technical information in this document is subject to change without notice.
