- Page 1 LC1502R USER’S GUIDE www.planar.com LC1502R User’s Guide (020-0315-01A)
-
Page 2: Table Of Contents
About the LC1502R ........ -
Page 3: Usage Notice
• Use a soft cloth moistened with mild detergent to clean the monitor housing. • Use only a high-quality and safety-approved 12V power supply. • Do not touch the LCD panel surface with sharp or hard objects. • Do not use abrasive cleaners, waxes or solvents for cleaning. LC1502R User’s Guide (020-0315-01A) -
Page 4: Introduction
Introduction About the LC1502R The LC1502R is a high performance monitor designed for demanding applications. The monitor consists of a 15" diagonal flat panel liquid crystal display (LCD) housed in a metal enclosure with an integrated ambient light sensor to facilitate automatic brightness control. -
Page 5: Package Overview
Package Overview VGA Signal Cable Quick Start Guide LC1502R User’s Guide (020-0315-01A) -
Page 6: Installation
Installation Product Overview • Front View • Rear View LC1502R User’s Guide (020-0315-01A) -
Page 7: Connector Descriptions
Standard D-sub Analog; 15-pin D-sub connector 2. Power Input Connector Connector type: 4-pin mini DIN socket Manufacturer: Singatron Enterprise Co. (Taiwan) Part Number: 2MJ-0402A120 Mating Connector: 2MP-0402 series Power Connector Pin Configuration Description +12V DC +12V DC Ground Ground LC1502R User’s Guide (020-0315-01A) -
Page 8: Mounting
+12V output Mounting M4 threaded holes are provided in the sides of the monitor housing for mounting purposes. The blind holes will accommodate 10 mm long screws. See the mechanical outline drawing 076-0579-00 at www.planar.com/support for details. LC1502R User’s Guide (020-0315-01A) -
Page 9: Start Your Installation
Notice: To ensure the LCD display will work well with your system, please configure the display mode of your graphic card for a 1024 x 768 resolution and a 75 Hz refresh rate. Figure 1.0 LC1502R User’s Guide (020-0315-01A) -
Page 10: User Controls
2. Increases the minimum brightness limit adjustment items. of the display image. Power Switch Switches on/off the power of the LCD display. Power LED 1.Green indicates the display is turned on. 2. Amber indicates the display in power- saving mode. LC1502R User’s Guide (020-0315-01A) -
Page 11: How To Use The Osd Menus
2. Choose the adjustment items by pressing the "Select/Auto" button. 3. Adjust the value of the adjustment items by pressing the "+" or "-" button. 4. The OSD menu will automatically close if you have left it idle for a pre-set time. LC1502R User’s Guide (020-0315-01A) -
Page 12: On-Screen Display Menus
Enables the display resolution. Disables the display resolution. RETURN Returns to the previous page. RESET Returns the display parameters of the current mode to its default settings. RETURN Returns to the previous page. Exits the OSD Menus EXIT LC1502R User’s Guide (020-0315-01A) -
Page 13: Brightness Control
The graph below shows the factory set response to ambient lighting conditions. Note that a typical office environment is 300 to 500 lux, while a typical cloudy day is roughly 1000 lux. Automatic brightness control with remote photo sensor. LC1502R User’s Guide (020-0315-01A) -
Page 14: Manual Brightness Control
A 20k pot or higher is recommended. Note that VREF is a 5V regulated voltage supplied through a 470 ohm series resistance. Important note! Do not connect to pin 2! Manual brightness control using a potentiometer LC1502R User’s Guide (020-0315-01A) -
Page 15: Minimum Brightness Limit
OSD controls are used to access and change the minimum brightness limit setting, as described in the User Controls section of this manual. Below is a graph showing the typical minimum brightness limit for a given OSD setting: LC1502R User’s Guide (020-0315-01A) -
Page 16: Maximum Brightness Mode
Maximum Brightness Mode If a constant maximum brightness is desired, simply connect both the DIM_INPUT and the /EXT_DIM inputs of connector J1 to ground. The monitor will then be set to the maximum brightness. LC1502R User’s Guide (020-0315-01A) -
Page 17: Specifications
Number of Supported Colors 262144 Note 1: 25°C steady state conditions at initial use Note 2: No dimming Note 3: With maximum dimming and factory set minimum brightness limit Note 4: With factory set minimum brightness limit LC1502R User’s Guide (020-0315-01A) -
Page 18: Mechanical And Environmental
1 grms, 1 hr / axis Sine sweep vibration, non-operating 10~500 Hz, 0.75g o-p, 0. 5 oct / min Random sweep vibration, non-operating 10~500 Hz, 0.0082 g2/Hz, 2 grms, 1 hr / axis Compatible Video Modes LC1502R User’s Guide (020-0315-01A) -
Page 19: Reliability And Life
IEC 61000-4-6: 2001 Immunity to conducted disturbances, induced by radio-frequency fields IEC 61000-4-8: 2001 Power frequency magnetic field immunity test IEC 61000-4-11: 2001 Voltage dips, short interruptions and voltage variations immunity tests C. UL/CUL Certification TUV Certification LC1502R User’s Guide (020-0315-01A) -
Page 20: Available Options
Available Options Power Supply and AC Power Cord The LC1502R requires a 12VDC power input. Many users will have the required 12VDC available in their existing system. Alternatively, a power supply that is appropriately rated for the LC1502R is available from Planar. The supply is available with the AC power cord configured with either a European plug or a US plug. -
Page 21: Cooling Kit
The total fan kit power consumption is approximately 3.6 watts with fans at max speed. Fan power is derived from the 12V input (4-pin DIN connector.) All cooling kit version monitors are shipped with the cooling kit pre-installed. Model Planar Part Number Description LC1502R-C 997-2823-xx LC1502R with cooling kit LC1502R User’s Guide (020-0315-01A) -
Page 22: Touch Screens
Touch Screens The LC1502R is available with two different types of touch screen technology: near field imaging (NFI) and capacitive. Both come pre-installed; the touch screen itself is mounted to the front of the monitor and the touch screen controller module is mounted on the back. NFI technology utilizes a thick glass substrate that provides “vandal-proof”... - Page 23 Set up 1. Refer to Planar mechanical outline drawing 076-0596-xx for the recommended mounting pattern for this display. 2. Separate the LCD monitor from the touch bezel for mounting. a. Remove the controller cover in order to remove the touch screen controller cable.
-
Page 24: Capacitive Touch Screen
Capacitive Touch Screen LC1502R with Capacitive Touch Screen The LC1502R with capacitive touch screen – model LC1502RTC – is designed to be installed in enclo- sures placed in high ambient lighting environments that are protected from extreme environmental conditions. It utilizes a standard 3M capacitive touch screen. -
Page 25: Appendix
If you are experiencing trouble with the LCD display, refer to the following. If the problem persists, please contact your local stat or visit Planar Support at www.Planar.com/support. See support contact information on rear cover. For all video image problems, first try using the Auto-Adjustment in the OSD menu Problem: No image appears on screen. -
Page 26: Mechanical Outline
Properties" in the Control Panel folder. Faint Horizontal Dark Lines Across the Screen This display is directly backlit by cold cathode fluorescent lamps. Slight brightness nonuniformity is normal. Mechanical Outline See mechanical outline drawing on www.planar.com/support LC1502R User’s Guide (020-0315-01A) -
Page 27: Warranty
Support and Service should reflect what's below: Support and Service Planar is a U.S. company based in Beaverton, Oregon and Espoo, Finland, with a world-wide sales distribution network. Full application engineering support and service are available to make the integration of Planar displays as simple and quick as possible for our customers. - Page 28 Email: IntlTech_Support@Planar.com Hours: M-F, 7am-4pm CET © 2005 Planar Systems, Inc. 03/05 Planar is a registered trademark of Planar Systems, Inc. Other brands and names are the property of their respective owners. Technical information in this document is subject to change without notice.
